Sonar System (Convertible): Removal & Installation Infiniti Q60 I

Collision/avoidance 4 illustrations ~135 words

REMOVAL

  1. Remove the instrument finisher A. Refer to " «A/T MODELS: EXPLODED VIEW»(ref-659773-S29636678492014100100000) " (A/T models) or " «M/T MODELS: EXPLODED VIEW»(ref-659773-S20593415822014100100000) " (M/T models).
  2. Remove sonar control unit screw, then disconnect sonar control unit connector and remove the sonar control unit.

INSTALLATION

Install in the reverse order of removal.

Scheme 17

Scheme 17: Exploded View
Scheme 17: Exploded View

Scheme 18

Scheme 18: REMOVAL
Scheme 18: REMOVAL
  1. Disconnect rear sensor connector.
  2. Press the spring fixing the sensor (1) (black arrows).
  3. Remove the sensor to the white arrow direction.

Install in the reverse order of removal.

CAUTIONThe connector direction is within ±10° from the horizontal position when assembling the bumper.

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20: Exploded View
Scheme 20: Exploded View
  1. Remove the instrument driver lower panel. Refer to " «A/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S31915970622014100100000) " (A/T models) or " «M/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S24721773792014100100000) " (M/T models).
  2. Disengage the pawls. And then remove sonar cancel switch.

Install in the reverse order of removal.
