System Description

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 19

Scheme 19: System diagram

Scheme 20

Scheme 20: Input/output signal chart

Scheme 21

Scheme 21

Scheme 22

Scheme 22: System diagram

Scheme 23

Scheme 23: Input/output signal chart

Scheme 24

Scheme 24

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 25

Scheme 25: Component Parts and Harness Connector Location

Note. For wiring diagram references to PG-POWER , see POWER DISTRIBUTION and GROUND DISTRIBUTION .

Scheme 26

Scheme 26: Wiring Diagram - CAN

Scheme 27

Scheme 27

Scheme 28

Scheme 28: Work Flow

Scheme 29

Scheme 29
  1. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "VDC", and "A/T" displayed on CONSULT-II
  2. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "VDC", and "A/T" displayed on CONSULT-II.
  3. Attach the printed sheet of "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to " «CHECK SHEET»(ref-182052-S28119281562005080900000) ".
  4. Based on the "CAN DIAG SUPPORT MNTR" results, put marks "v" onto the items with "NG" or "UNKWN" in the check sheet table. Refer to " «CHECK SHEET»(ref-182052-S28119281562005080900000) ". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
  5. According to the check sheet results (example), start inspection. Refer to " «CHECK SHEET RESULTS (EXAMPLE)»(ref-182052-S08713928842005080900000) ".

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

Scheme 30

Scheme 30: Component Parts and Harness Connector Location

Scheme 31

Scheme 31: Schematic

Note. For wiring diagram references to PG-POWER , see POWER DISTRIBUTION and GROUND DISTRIBUTION .

Scheme 32

Scheme 32: Wiring Diagram - CAN

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35: Work Flow

Scheme 36

Scheme 36
  1. Print all the data of "SELF-DIAG RESULTS" for "ENGINE", "VDC", "ICC", and "A/T" displayed on CONSULT-II.
  2. Print all the data of "CAN DIAG SUPPORT MNTR" for "ENGINE", "VDC", "ICC", and "A/T" displayed on CONSULT-II.
  3. Attach the printed sheet of "SELF-DIAG RESULTS" and "CAN DIAG SUPPORT MNTR" onto the check sheet. Refer to " «CHECK SHEET»(ref-182052-S05436127902005080900000) ".
  4. Based on the "CAN DIAG SUPPORT MNTR" results, put marks "v" onto the items with "NG" or "UNKWN" in the check sheet table. Refer to " «CHECK SHEET»(ref-182052-S05436127902005080900000) ". NOTE: If "NG" is displayed on "INITIAL DIAG (Initial diagnosis)" as "CAN DIAG SUPPORT MNTR" for the diagnosed control unit, replace the control unit.
  5. According to the check sheet results (example), start inspection. Refer to " «CHECK SHEET RESULTS (EXAMPLE)»(ref-182052-S14075296942005080900000) ".
