Exterior lamps circuit for Infiniti Q45 II (1996-2001)

105 60 68 6 11 14 114 56 113 BATT AUTO HEAD AUTO OFF BLK WIRE BLU WIRE BLU/BLK WIRE BLU/YEL (OR BLU/WHT OR PPL/RED) WIRE BLU/YEL WIRE BODY CONTROL MODULE (BCM) (BEHIND DASH, RIGHT OF STEERING COLUMN) COMBINATION FLASHER UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) COMBINATION METER COMBINATION SWITCH (LIGHTING SWITCH) FUSE 13 FUSE 14 FUSE 19 FUSE 23 FUSE 32 FUSE 37 FUSE BLOCK (BEHIND LEFT SIDE OF DASH) GRN RED/ WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD SWITCH HOT AT ALL TIMES HOT IN ON OR ACCY HOT IN ON OR START IGN HAZARD TAILLIGHT RELAY LIGHT SW (AUTO) A/D GND GND GND JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH, NEAR FUSE BLOCK) JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH, NEAR FUSE BLOCK) JOINT CONNECTOR 3 (BEHIND LEFT SIDE OF DASH, NEAR FUSE BLOCK) JOINT CONNECTOR 4 (BEHIND UPPER LEFT SIDE OF DASH) LEFT LEFT FRONT COMBINATION LAMP ORG/ WIRE PARK PARK HEAD PARK TURN PNK WIRE PNK/BLU WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT RIGHT END OF DASH) RIGHT FRONT COMBINATION LAMP YEL/RED (OR WHT/PPL) WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE FUSE 63 FUSE BLOCK (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK, RELAY BOX (RIGHT FRONT SIDE OF ENGINE COMPT, NEAR BATTERY) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HIGH MOUNTED STOP LAMP HOT AT ALL TIMES JOINT CONN- ECTOR 15 (IN FUSE, FUSIBLE LINK, RELAY BOX) LEFT REAR COMBINATION LAMP LICENSE LAMPS LT BLU WIRE MULTI-REMOTE CONTROL RELAY (IN RIGHT FRONT CORNER OF LUGGAGE COMPT) NCA WIRE PNK/BLU WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT REAR COMBINATION LAMP STOP TAIL STOP, TAILLIGHT SENSOR (IN REAR OF LUGGAGE COMPT) STOPLAMP SW A TAIL TAILLIGHT RELAY (IN FUSE, FUSIBLE LINK, RELAY BOX) TURN SIGNAL SWITCH TURN TURN WARNING SYSTEMS WHT WIRE WHT/GRN WIRE YEL/RED WIRE
