INSTALLATION

1. The dam rubber and insulator should be installed in position.
2. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
3. Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by passenger room air pressure when all door windows are closed.
4. The molding must be installed securely so that it is in position and leaves no clearance.
5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity.

REMOVAL

1. Remove the rear pillar finisher (LH/RH). Refer to " «REMOVAL AND INSTALLATION»(ref-356266-S32307707132010021300000) ".
2. Remove the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-356266-S19899371612010021300000) ".
3. Apply protective tape around the side window to protect the painted surface from damage.
4. Remove the side window glass using piano wire or power cutting tool and an inflatable pump bag. WARNING: Always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands when cutting the glass from the vehicle. CAUTION: Be careful not to scratch the glass when removing. Never set or stand the glass on its edge. Small chips may develop into cracks.

1. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
2. Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by passenger room air pressure when all door windows are closed.
3. The molding must be installed securely so that it is in position and leaves no clearance.
4. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity.

1. Remove rear seatback and rear seat cushion. Refer to " «REMOVAL AND INSTALLATION»(ref-356253-S02705685542010021300000) ".
2. Remove the rear pillar finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-356266-S32307707132010021300000) ".
3. Remove the rear parcel shelf finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-356266-S06723864392010021300000) ".
4. Remove the rear of headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-356266-S19899371612010021300000) ".
5. Remove the connectors and grounds for the back door window defogger.
6. Remover the roof side molding. Refer to " «REMOVAL AND INSTALLATION»(ref-356266-S39853402092010021300000) ".
7. Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing molding using pliers. NOTE: Mark the body and the glass with matching marks if a rear window glass is reused. WARNING: Always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands when cutting the glass from the vehicle. CAUTION: Never use a cutting knife or power cutting tool when the back door window glass is reused. Be careful not to scratch the glass when removing. Never set or stand the glass on its edge. Small chips may develop into cracks.

1. The dam rubber should be installed in position.
2. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
3. Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by passenger compartment air pressure when all door windows are closed.
4. The molding must be installed securely so that it is in position and leaves no clearance.
5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (approximately 24 hours). Curing time varies with temperature and humidity. WARNING: Keep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let them in contact with the skin and eyes. Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled. Move immediately to an area with fresh air if affected by vapor inhalation. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the rear window in case of an accident. CAUTION: Never use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Adhere carefully to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Never leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time increases under lower temperature and lower humidity.

Install in the reverse order of removal.

Scheme 36

1. Remove the front door finisher. Refer to «DOOR FINISHER»(ref-356266-S34729492292010021300000) .
2. Operate the power window main switch to raise/lower the door window until the glass mounting bolts can be seen.
3. Remove the glass mounting bolts.
4. Raise up the door glass and hold with a suction lifter A.
5. Remove the mounting bolts, and remove the module assembly.
6. Disconnect the harness connector for the module assembly, and unclip the harness from the inside.

Install in the reverse order of removal.

Inspection after Removal

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

1. Wire wear
2. Regulator deformation
3. Grease condition for each sliding part

The arrows in the figure show the application points of the multi-purpose grease.

Scheme 37

Install in the reverse order of removal.

Scheme 38

Scheme 39

1. Remove the rear door finisher. Refer to «DOOR FINISHER»(ref-356266-S34729492292010021300000) .
2. Remove the rear door inner frame.
3. Operate the power window switch to raise/lower the door window until the glass mounting bolts can be seen.
4. Remove the glass mounting bolts.
5. Raise up the door glass and hold with a suction lifter A.
6. Disconnect the connector for the regulator assembly.
7. Remove the regulator mounting bolts, and remove the regulator from the door panel.

Install in the reverse order of removal.

Inspection after Removal

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

1. Gear wear
2. Regulator deformation
3. Grease condition for each sliding part

The arrows in the figure show the application points of the multi-purpose grease.

Scheme 40

1. Remove rain sensor cover.
2. Remove screw of mirror base.
3. Slide the mirror upward to remove.
4. Disconnect the connector.

Install in the reverse order of removal.

Scheme 41

1. Remove the front door finisher. Refer to «DOOR FINISHER»(ref-356266-S34729492292010021300000) .
2. Remove the front door sash cover inner. Refer to " «COMPONENT PARTS LOCATION»(ref-356266-S16105539312010021300000) ".
3. Remove the door mirror harness connector.
4. Remove the door mirror mounting nuts, and remove the door mirror assembly.

Install in the reverse order of removal.

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Place the mirror body with mirror glass facing upward.
2. Put a strip of protective tape B on mirror body.
3. As shown in the figure, insert a small slotted screwdriver (A) into the recess between mirror base (mirror holder) (1) and mirror holder bracket (2) and push up two pawls (3) to remove mirror holder lower half side. NOTE: When pushing up pawls do not attempt to use one recess only, be sure to push up with both recesses. Insert screwdriver into recesses, and push up while rotating (twist) to make work easier.
4. Remove two terminals of mirror heater attachment.
5. Lightly lift up lower side of mirror surface from mirror surface, and detach two pawls of upper side as if pulling it out. Remove mirror surface from mirror body. NOTE: Be certain not to allow grease on sealing agent in center of mirror body assembly (actuator) or back side of mirror surface (mirror holder).
6. Remove the clips and mirror cover from the housing.
7. Remove the screws and actuator from the housing.

Scheme 46

1. Install the actuator.
2. Install the mirror cover.
3. Place mirror holder bracket and mirror body assembly (actuator) in a horizontal position.
4. Connect two terminals of heater installed mirror.
5. Fit the upper two pawls on the mirror face (1) onto the mirror holder bracket (2) first, then press the lower side of mirror face until a click sound is heard to engage the lower pawls. NOTE: After installation, visually make sure lower two pawls are securely engaged from the bottom of mirror face.
