Scheme 26
Scheme 27
Scheme 28
- Vehicle speed sensing electronically controlled power steering (that properly controls the steering force by the vehicle speed) has been adopted. When it is normal, it controls the power steering solenoid valve according to the vehicle speed as shown in the figure and makes the steering force proper.
- For the models with RAS (Rear Active Steer), RAS control unit performs the same control as power steering control unit. For schematic, refer to " «WIRING DIAGRAM - RAS»(ref-356291-S18107261912010021300000) "and trouble diagnosis, refer to " «DIAGNOSIS CHART BY SYMPTOM 2»(ref-356291-S30850805372010021300000) ".
Fail-Safe Function
When the fail-safe function operate, it controls power steering solenoid valve by the engine speed as shown in the figure and maintains the steering force.
Scheme 29
FAIL-SAFE INPUT/CANCEL CONDITIONS
| Input conditions | Cancel conditions |
|---|---|
| When vehicle runs at an engine speed of 1, 500 rpm or higher and no vehicle speed signal is received for 10 seconds. | A vehicle speed of 2 km/h (1.2 MPH) or more is input. Turn the ignition switch ON after turning it OFF. |
| The continuous vehicle speed signal 30 km/h (19 MPH) or more suddenly drops to less than 2 km/h (1.2 MPH) within 1.4 seconds. |
FAIL-SAFE CONDITIONS CHART
| CAUTION | Fail-safe function is activated when the engine runs at 1, 500 rpm or higher for 10 seconds with the vehicle stopped. This is normal and the fail-safe function is automatically deactivated when a vehicle speed signal of 2 km/h (1.2 MPH) or higher is input or the ignition switch is turned OFF. |
Scheme 30
Scheme 31
- The most important point to perform trouble diagnosis is to understand systems (control and mechanism) in vehicle thoroughly.
- It is also important to clarify customer complaints before inspection. First of all, reproduce symptom, and understand it fully. Ask customer about his/her complaints carefully. In some cases, they will be necessary to check symptom by driving vehicle with customer. CAUTION: Customers are not professionals. Do not assume "maybe customer means..." or "maybe customer mentioned this symptom".
- It is essential to check symptoms right from beginning in order to repair a malfunction completely. For an intermittent malfunction, it is important to reproduce symptom based on interview with customer and past examples. Do not perform inspection on ad hoc basis. Most intermittent malfunctions are caused by poor contacts. In this case, it will be effective to shake suspected harness or connector by hand. When repairs are performed without any symptom check, no one can judge if malfunction has actually been eliminated.
- Always read "GI General Information" to confirm general precautions. Refer to " «GENERAL PRECAUTION»(ref-356247-S17396993182010021300000) ".
Scheme 32
Scheme 33
Scheme 34
STANDARD BY CIRCUIT TESTER AND OSCILLOSCOPE
| CAUTION | When checked using a circuit tester for voltage measurement, connector terminals should not be forcefully extended. |
TERMINAL REFERENCE Terminal Measuring point Measuring condition Standard + (wire color) - 1 (GR) Ground IGN Ignition switch ON. Battery voltage (Approx. 12 V) 2 (B) Ground - - 3 (L) Vehicle speed signal (2-pulse) At 40 km/h (25 MPH) 5 (Y) Engine speed signal At idle after warming up At approx. 2, 000 rpm 7 (G) Power steering solenoid valve Normal (Vehicle speed) 0 km/h (0 MPH) Approx. 4.4 - 6.6 V 100 km/h (62 MPH) Approx. 2.4 - 3.6 V In fail-safe mode (Engine speed) 0 - 1, 500 rpm Approx. 4.4 - 6.6 V 1, 500 - 3, 000 rpm Approx. 3.5 V More than 3, 000 rpm Approx. 2.1 V
Scheme 35
Scheme 36
POWER SUPPLY CIRCUIT TERMINAL LOOSENESS AND BATTERY
Check battery terminals for looseness on both positive and negative ones and ground connection. Also make sure that battery voltage does not drop.
Scheme 37
Scheme 38
- CHECK POWER STEERING CONTROL UNIT CONNECTOR Turn ignition switch OFF, disconnect power steering control unit harness connector, and check terminal for deformation, disconnection, looseness, etc. OK or NG OK: GO TO 2. NG: Connector terminal connection is loose, damaged, open, or shorted. Repair or replace the terminal.
- CHECK POWER STEERING CONTROL UNIT GROUND CIRCUIT Disconnect power steering control unit harness connector M8, and then check continuity between power steering control unit harness connector M8 and ground. Terminal 2 - Ground : Continuity exist . OK or NG OK: GO TO 3. NG: Ground circuit open or shorted. Repair or replace any inoperative parts.
- CHECK POWER STEERING CONTROL UNIT POWER SUPPLY CIRCUIT Turn ignition switch ON, and then check voltage between power steering control unit harness connector M8 and ground. Terminal 1 - ground : Battery voltage (Approx. 12 V) OK or NG OK: Power supply and ground circuit are normal. NG: Power supply circuit open or shorted. Repair or replace any inoperative parts.
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the "SUPPLEMENTAL RESTRAINT SYSTEM" and "SEAT BELTS" of this Service Manual.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the " SUPPLEMENTAL RESTRAINT SYSTEM ". Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
Scheme 39
