Glasses, Window System & Mirrors: Removal & Installation Infiniti M45 III

Windows 16 illustrations ~1176 words

REMOVAL

  1. Remove the front pillar garnish. Refer to " «BODY SIDE TRIM»(ref-239112-S14407850202006072600000) ".
  2. Partially remove the headlining (front edge). Refer to " «HEADLINING»(ref-239112-S15919670542006072600000) ".
  3. Remove the front wiper arms. Refer to " «REMOVAL AND INSTALLATION OF FRONT WIPER ARMS, ADJUSTMENT OF WIPER ARMS STOP LOCATION»(ref-239137-S28872911192006072600000) ".
  4. Remove the cowl top cover. Refer to " «COWL TOP»(ref-239112-S10064888692006072600000) ".
  5. Remove roof side molding. Refer to " «ROOF SIDE MOLDING»(ref-239112-S23104380782006072600000) ".
  6. Apply a protective tape around the windshield glass to protect the painted surface from damage.

After removing moldings, remove glass using piano wire or power cutting tool A and an inflatable pump bag B.

Scheme 94

Scheme 94
Scheme 94
  1. If a windshield glass is to be reused, mark the body and the glass with mating marks. WARNING: When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands. CAUTION: When a windshield glass is to be reused, do not use a cutting knife or power cutting tool. Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

  1. The dam rubber should be installed in position.
  2. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  3. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
  4. The molding must be installed securely so that it is in position and leaves no gap.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the windshield in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperature and lower humidity.
  1. Remove the rear pillar finisher. Refer to " «REAR PILLAR FINISHER»(ref-239112-S09318250342006072600000) ".
  2. Remove the headlining. Refer to " «HEADLINING»(ref-239112-S15919670542006072600000) ".
  3. Apply protective tape around the side window to protect the painted surface from damage.
  4. Remove the side window glass using piano wire or power cutting tool and an inflatable pump bag.
WARNINGWhen cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands.
CAUTIONBe careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks.
  1. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
  3. The molding must be installed securely so that it is in position and leaves no gap.
  4. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the side window in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperature and lower humidity.
  1. Remove rear seatback and rear seat cushion. Refer to " «REAR SEAT»(ref-239127-S28034759792006072600000) ".
  2. Remove the rear pillar finisher. Refer to " «REAR PILLAR FINISHER»(ref-239112-S09318250342006072600000) ".
  3. Remove the rear parcel shelf finisher. Refer to " «REAR PARCEL SHELF FINISHER»(ref-239112-S13105811302006072600000) ".
  4. Remove the rear of the headlining. Refer to " «HEADLINING»(ref-239112-S15919670542006072600000) ".
  5. Remove the connectors and grounds for the rear window defogger and printed antenna.
  6. Remove the roof side molding. Refer to " «ROOF SIDE MOLDING»(ref-239112-S23104380782006072600000) ".
  7. After removing molding using pliers, remove glass using piano wire or power cutting tool A and an inflatable pump bag B.

Scheme 95

Scheme 95
Scheme 95
  1. If a rear window glass is reused, mark the body and the glass with mating marks.
WARNINGWhen cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands.
CAUTIONWhen a rear window glass is reused, do not use a cutting knife or power cutting tool. Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks.
  1. The dam rubber should be installed in position.
  2. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  3. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
  4. The molding must be installed securely so that it is in position and leaves no gap.
  5. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the rear window in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperature and lower humidity.

Scheme 96

Scheme 96: Removal and Installation
Scheme 96: Removal and Installation

Scheme 97

Scheme 97: Removal
Scheme 97: Removal
  1. Remove the front door finisher. Refer to " «DOOR FINISHER»(ref-239112-S26472424872006072600000) ".
  2. Remove the front door sash cover inner. Refer to " «FRONT DOOR SASH COVER INNER»(ref-239112-S01732694232006072600000) "
  3. Operate the power window main switch to raise/lower the door window until the glass mounting bolts can be seen.
  4. Remove the glass mounting bolts.
  5. While holding the door glass, raise it at the rear end to pull the glass out of the sash toward the inside of the door.

Scheme 98

Scheme 98
Scheme 98

Install in the reverse order of removal.

Scheme 99

Scheme 99: Removal
Scheme 99: Removal

Scheme 100

Scheme 100
Scheme 100
  1. Remove the front door finisher. Refer to " «DOOR FINISHER»(ref-239112-S26472424872006072600000) ".
  2. Operate the power window main switch to raise/lower the door window until the glass mounting bolts can be seen.
  3. Remove the glass mounting bolts.
  4. Raise up the door glass and hold with a suction lifter A.
  5. Remove the mounting bolts, and remove the module assembly.
  6. Disconnect the harness connector for the module assembly, and unclip the harness from the inside.

Install in the reverse order of removal.

Install in the reverse order of removal.

Scheme 101

Scheme 101: Removal
Scheme 101: Removal

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103
  1. Remove the rear door finisher. Refer to " «DOOR FINISHER»(ref-239112-S26472424872006072600000) ".
  2. Remove the rear door inner frame.
  3. Operate the power window switch to raise/lower the door window until the glass mounting bolts can be seen.
  4. Remove the glass mounting bolts.
  5. Raise up the door glass and hold with a suction lifter A.
  6. Disconnect the connector for the regulator assembly.
  7. Remove the regulator mounting bolts, and remove the regulator from the door panel.

Scheme 104

Scheme 104
Scheme 104

Install in the reverse order of removal.

  1. Remove inside mirror finisher (if equipped).
  2. Remove screw of mirror base.
  3. Slide the mirror upward to remove.
  4. Disconnect the connector (if equipped).

Install in the reverse order of removal.

Scheme 105

Scheme 105: Component Parts and Harness Connector Location
Scheme 105: Component Parts and Harness Connector Location
  1. Remove the front door finisher. Refer to " «DOOR FINISHER»(ref-239112-S26472424872006072600000) ".
  2. Remove the front door sash cover inner. Refer to " «FRONT DOOR SASH COVER INNER»(ref-239112-S01732694232006072600000) ".
  3. Remove the door mirror harness connector.
  4. Remove the door mirror mounting nuts, and remove the door mirror assembly.

Install in the reverse order of removal.

Scheme 106

Scheme 106: Disassembly and Assembly
Scheme 106: Disassembly and Assembly

Scheme 107

Scheme 107: DISASSEMBLY
Scheme 107: DISASSEMBLY

Scheme 108

Scheme 108
Scheme 108
  1. Place the mirror body with mirror glass facing upward.
  2. Put a strip of protective tape B on mirror body.
  3. As shown in the figure, insert a small slotted screwdriver A into the recess between mirror base (mirror holder)(1) and mirror holder bracket (2) and push up two pawls (3) to remove mirror holder lower half side. NOTE: When pushing up pawls do not attempt to use one recess only, be sure to push up with both recesses. Insert screwdriver into recesses, and push up while rotating (twist) to make work easier.
  4. Remove two terminals of mirror heater attachment.
  5. Lightly lift up lower side of mirror surface from mirror surface, and detach two pawls of upper side as if pulling it out. Remove mirror surface from mirror body. NOTE: Be certain not to allow grease on sealing agent in center of mirror body assembly (actuator) or back side of mirror surface (mirror holder).
  6. Remove the clips and mirror cover from the housing.
  7. Remove the screws and power unit from the housing.

Scheme 109

Scheme 109
Scheme 109
