Parts Requiring Angle Tightening
- Use angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts: Cylinder head bolts Main bearing cap bolts Connecting rod cap nuts Crankshaft pulley bolt (No angle wrench is required as the bolt flange is provided with notches for angle tightening)
- Do not use a torque value for final tightening.
- The torque value for these parts are for a preliminary step.
- Ensure thread and seat surfaces are clean and coated with engine oil.
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS Cylinder arrangement V-8 Displacement cm 3 (cu in) 4,494 (274.22) Bore and stroke mm (in) 93 x 82.7 (3.66 x 3.256) Valve arrangement DOHC Firing order 1-8-7-3-6-5-4-2 Number of piston rings Compression 2 Oil 1 Number of main bearings 5 Compression ratio 10.5 Compression pressure kPa (kg/cm 2 , psi)/300 RPM Standard 1,320 (13.5, 191) Minimum 1,130 (11.5, 164) Differential limit between cylinders 98 (1.0, 14) Cylinder number Valve timing Unit: degree a b c d e f 228 240 -2 62 4 44
Scheme 1
Scheme 2
