Engine Mechanical: Overhaul Infiniti M35 III рестайлинг

DISASSEMBLY

1. Remove spark plug with spark plug wrench (commercial service tool).
2. Remove valve lifter. Identify installation positions, and store them without mixing them up.
3. Remove valve collet. Compress valve spring with valve spring compressor [SST: KV10116200 (J26336-A)] (A), attachment [SST: KV10115900 (J26336-20)] (C) and adapter [SST: KV10109220 (-)] (B). Remove valve collet with magnet hand. CAUTION: When working, take care not to damage valve lifter holes.
4. Remove valve spring retainer, valve spring and valve spring seat.
5. Push valve stem to combustion chamber side, and remove valve. Identify installation positions, and store them without mixing them up.
6. Remove valve oil seals using valve oil seal puller [SST: KV10107902 (J38959)] (A).
7. If valve seat must be replaced, refer to " «INSPECTION AFTER DISASSEMBLY»(ref-356257-S33741824582010021300000) ".
8. If valve guide must be replaced, refer to " «INSPECTION AFTER DISASSEMBLY»(ref-356257-S33741824582010021300000) ".
9. Remove spark plug tube, if necessary. Using pair of pliers, pull spark plug tube out of cylinder head. CAUTION: Take care not to damage cylinder head. Once removed, spark plug tube will be deformed and cannot be reused. Never remove it unless absolutely necessary.

Scheme 245

Scheme 246

1. When valve guide is removed, install it. Refer to " «INSPECTION AFTER DISASSEMBLY»(ref-356257-S33741824582010021300000) ".
2. When valve seat is removed, install it. Refer to " «INSPECTION AFTER DISASSEMBLY»(ref-356257-S33741824582010021300000) ".
3. Install valve oil seals. Install with valve oil seal drift [SST: KV10115600 (J38958)] (A) to match dimension in the figure. Height (b) (Without valve spring seat installed) Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in)
4. Install valve spring seat.
5. Install valves. NOTE: Larger diameter valves are for intake side.
6. Install valve spring (uneven pitch type). Install narrow pitch (B) end [paint mark (C)] to cylinder head side (valve spring seat side). Paint mark color : Yellowish green
7. Install valve spring retainer.
8. Install valve collet. Compress valve spring with valve spring compressor [SST: KV10116200 (J26336-A)] (A), attachment [SST: KV10115900 (J26336-20)] (C) and adapter [SST: KV10109220 (-)] (B). Install valve collet with magnet hand. CAUTION: When working, take care not to damage valve lifter holes. Tap valve stem edge lightly with plastic hammer after installation to check its installed condition.
9. Install valve lifter. Install it in the original position.
10. Install spark plug tube. Press-fit spark plug tube as follows: Remove old liquid gasket adhering to cylinder head mounting hole. Apply liquid gasket to area within approximately 12 mm (0.47 in) from edge of spark plug tube press-fit side. Use genuine high strength thread locking sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCT AND SEALANT»(ref-356247-S32913053182010021300000) ". Using drift, press-fit spark plug tube so that its height (A) is as specified in the figure. Standard press-fit height : 37.7 - 38.7 mm (1.484 - 1.524 in) CAUTION: When press-fitting, take care not to deform spark plug tube. After press-fitting, wipe off liquid gasket protruding onto cylinder-head upper face.
11. Install spark plug with spark plug wrench (commercial service tool).
