Engine Mechanical: Specifications Infiniti I35 II

Mechanical 25 illustrations ~219 words

Parts Requiring Angular Tightening

  1. Use an angle wrench for the final tightening of the following engine parts: Cylinder head bolts Main bearing cap bolts Connecting rod cap nuts Crankshaft pulley bolt
  1. Do not use a torque value for final tightening.
  2. The torque value for these parts are for a preliminary step.
  3. Ensure thread and seat surfaces are clean and coated with engine oil.

Scheme 1

Scheme 1: Liquid Gasket Application Procedure

Scheme 2

Scheme 2
  1. Use a scraper to remove all traces of old liquid gasket from mating surfaces and grooves. Also, completely clean any oil from these areas.
  2. Apply a continuous bead of liquid gasket to mating surfaces. (Use Genuine RTV silicone sealant or equivalent. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-180422-S02321372872005072600000) .) Be sure liquid gasket diameter is as specified in this manual.
  3. Apply liquid gasket around the inner side of bolt holes (unless otherwise specified).
  4. Assembly should be done within 5 minutes after coating.
  5. Wait at least 30 minutes before refilling engine oil and engine coolant.

General Specifications

Cylinder arrangementV-6
Displacement cm 3 (cu in)3,498 (213.45)
Bore and stroke mm (in)95.5 x 81.4 (3.760 x 3.205)
Valve arrangementDOHC
Firing order1-2-3-4-5-6
Number of piston ringsCompression2
Oil1
Number of main bearings4
Compression ratio10.3

Identifying General Specifications

Scheme 3

Scheme 3: Compression Pressure

Scheme 4

Scheme 4: Cylinder Head

Scheme 5

Scheme 5: VALVE

Scheme 6

Scheme 6: VALVE CLEARANCE

Scheme 7

Scheme 7: VALVE SPRING

Scheme 8

Scheme 8: VALVE LIFTER

Scheme 9

Scheme 9

Scheme 10

Scheme 10: VALVE GUIDE

Scheme 11

Scheme 11: Valve Seat

Scheme 12

Scheme 12: Camshaft and Camshaft Bearing

Scheme 13

Scheme 13

Scheme 14

Scheme 14: Cylinder Block

Scheme 15

Scheme 15: AVAILABLE PISTON

Scheme 16

Scheme 16: PISTON RING

Scheme 17

Scheme 17: PISTON PIN

Scheme 18

Scheme 18: Connecting Rod

Scheme 19

Scheme 19: Crankshaft

Scheme 20

Scheme 20: Available Main Bearing

Scheme 21

Scheme 21: UNDERSIZE

Scheme 22

Scheme 22: CONNECTING ROD BEARING

Scheme 23

Scheme 23: UNDERSIZE

Scheme 24

Scheme 24: Miscellaneous Components

Scheme 25

Scheme 25: BEARING CLEARANCE
