Board Computer: Maintenance Infiniti I35 II

Gauges & Instrument Panels 2 illustrations ~124 words

HOW TO CHANGE/RESET INDICATION

  1. Indication can be changed by in following order by pushing board computer steering switch "TRIP". OUTSIDE AIR TEMPERATURE --> RANGE --> AVERAGE FUEL CONSUMPTION --> AVERAGE VEHICLE SPEED --> JOURNEY TIME
  2. Continuous pushing the switch (more than 0.8 second) can reset the indication of journey time (hour meter), average vehicle speed and average fuel consumption.

Note. After the display changes automatically, the indication can be changed to the last mode by pushing the board computer steering switch. In this case, the cursor ("***") will blink as a warning. When the OUTSIDE AIR TEMPERATURE warning and the RANGE warning match warning conditions at the same time, the display automatically indicates the OUTSIDE AIR TEMPERATURE.

Scheme 13

Scheme 13: Wiring Diagram - B/COMP

Scheme 14

Scheme 14
