Engine Cooling System Service: Maintenance Infiniti I35 II

Refilling Engine Coolant

For details on refilling engine coolant, refer to COOLING SYSTEM BLEEDING .

Scheme 9

Scheme 10

1. Attach the spacer to the tip of the radiator plate pliers A. Spacer specification: 1.5 mm (0.059 in) thick x 18 mm (0.71 in) wide x 8.5 mm (0.335 in) long.
2. Make sure that when radiator plate pliers A are closed dimension H" is approx. 7.6 mm (0.299 in).
3. Adjust dimension H" with the spacer, if necessary.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Remove tank with Tool. Grip the crimped edge and bend it upwards so that Tool slips off. Do not bend excessively. In areas where Tool cannot be used, use a screwdriver to bend the edge up. Be careful not to damage tank.
2. Make sure the edge stands straight up.
3. Remove oil cooler from tank. (A/T models only)

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Install oil cooler. (A/T models only) Pay attention to direction of conical washer.
2. Clean contact portion of tank.
3. Install sealing rubber. Push it in with fingers. Be careful not to twist sealing rubber.
4. Caulk tank in specified sequence with Tool. Use pliers in the locations where Tool cannot be used.
5. Make sure that the rim is completely crimped down. Standard height "H": 8.0 - 8.4 mm (0.315 - 0.331 in)
6. Confirm that there is no leakage. Refer to Inspection.
