PISTON SELECTION TABLE

Unit: mm (in)
Grade123
Cylinder bore inner diameter95.500 - 95.510 (3.7598 - 3.7602)95.510 - 95.520 (3.7602 - 3.7606)95.520 - 95.530 (3.7606 - 3.7610)
Piston skirt diameter95.480 - 95.490 (3.7590 - 3.7594)95.490 - 95.500 (3.7594 - 3.7598)95.500 - 95.510 (3.7598 - 3.7602)

PISTON SELECTION CHART

Note. Piston is available together with piston pin as assembly. Piston pin (piston pin hole) grade is provided only for the parts installed at the plant. For service parts, no piston pin grades can be selected. (Only "0" grade is available.) No second grade mark is available on piston.

Scheme 589

Scheme 589: WHEN NEW CONNECTING ROD AND CRANKSHAFT ARE USED
Scheme 589: WHEN NEW CONNECTING ROD AND CRANKSHAFT ARE USED

Scheme 590

Scheme 590
Scheme 590
  1. Apply connecting rod big end diameter grade stamped (D) on connecting rod side face to the row in the "CONNECTING ROD BEARING SELECTION TABLE".
  2. Apply crankshaft pin journal diameter grade stamped on crankshaft front side to the column in the "CONNECTING ROD BEARING SELECTION TABLE"
  3. Read the symbol at the cross point of selected row and column in the "CONNECTING ROD BEARING SELECTION TABLE".
  4. Apply the symbol obtained to the "CONNECTING ROD BEARING GRADE TABLE" to select connecting rod bearing.
