MINIMUM SPECIFICATION OF CRANKING VOLTAGE REFERENCING COOLANT TEMPERATURE
| Engine coolant temperature | Voltage V |
|---|---|
| 30°C to -20°C (-22°F to -4°F) | 8.4 |
| 19°C to -10°C (-2°F to 14°F) | 8.9 |
| 9°C to 0°C (16°F to 32°F) | 9.3 |
| More than 1°C (More than 34°F) | 9.7 |
ENGINE COOLANT TEMPERATURE SPECIFICATION
Scheme 57
Scheme 58
- Open the driver and front passenger window, and then disconnect the battery negative cable. CAUTION: Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interference between the window edge and the vehicle when the door is opened/closed. During normal operation, the window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic window function will not work with the battery disconnected.
- Remove engine rear undercover, using power tools.
- Disconnect S connector.
- Remove B terminal nut.
- Remove starter motor mounting bolts and harness connector clip bracket, using power tools.
- Remove starter motor to the direction of under side the vehicle.
