Component Locations
Note. For engine compartment fuse, fusible link and relay box locations (Scheme 1)
- Fuse and fusible link block is located at passenger's side of engine compartment. For component identification (Scheme 4)and (Scheme 5). For circuit wiring diagram, see «POWER DISTRIBUTION»(ref-166525-S16760524712004092200000) in SYSTEM WIRING DIAGRAMS article.
- Relay box, if manufactured in Canada, is located at passenger's side of engine compartment. For component descriptions (Scheme 1)
- VDC Relay box is located at driver's side of engine compartment. See appropriate ANTI-LOCK/TRACTION CONTROL article in BRAKES.
- Fusible link holder is located at passenger's side of engine compartment near battery connectors. For component locations (Scheme 2) For component identification (Scheme 4), (Scheme 9) and (Scheme 13). For circuit wiring diagram, see «POWER DISTRIBUTION»(ref-166525-S16760524712004092200000) in SYSTEM WIRING DIAGRAMS article.
- IPDM is located at passenger's side of engine compartment. For relay locations (Scheme 3) For component identification (Scheme 6)- (Scheme 8) and (Scheme 12) - (Scheme 14). For circuit wiring diagram, see «POWER DISTRIBUTION»(ref-166525-S16760524712004092200000) in SYSTEM WIRING DIAGRAMS article.
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Note. For instrument panel and passenger area fuse block, relay, control module and unit locations (Scheme 15), (Scheme 16) and (Scheme 17).
- Circuit breaker is located behind driver's side kick panel. For circuit breaker location (Scheme 16) For component identification (Scheme 4)
- Fuse block is located behind driver's side kick panel. For component identification (Scheme 5), (Scheme 9) - (Scheme 12) and (Scheme 14). For circuit wiring diagram, see «POWER DISTRIBUTION»(ref-166525-S16760524712004092200000) in SYSTEM WIRING DIAGRAMS article.
