Audio, Visual, Navigation System (Without Navigation): Removal & Installation Infiniti FX50 II

REMOVAL

1. Remove front display unit. Refer to «REMOVAL AND INSTALLATION»(ref-368887-S19032328622010081300000) .
2. Remove AV control unit with a unified meter and A/C amp. as a single unit from the body.
3. Remove bracket screws, and then remove AV control unit.

INSTALLATION

Installation is the reverse order of removal.

Scheme 50

Scheme 51

1. Remove cluster lid D. Refer to «REMOVAL AND INSTALLATION»(ref-368874-S04233062632010081300000) .
2. Remove front display unit mounting screws.
3. Disconnect connector, and remove front display unit.

Installation is the reverse order of removal.

Scheme 52

1. Remove front door finisher. Refer to «REMOVAL AND INSTALLATION»(ref-368866-S42566746702010081300000) .
2. Remove front door speaker mounting bolts.
3. Disconnect connector and remove front door speaker.

Installation is the reverse order of removal.

Scheme 53

1. Remove rear door finisher. Refer to «REMOVAL AND INSTALLATION»(ref-368866-S06176499132010081300000) .
2. Remove rear door speaker mounting bolts.
3. Disconnect connector and remove rear door speaker.

Installation is the reverse order of removal.

Scheme 54

1. Remove speaker grille. Refer to «REMOVAL AND INSTALLATION»(ref-368874-S04233062632010081300000) .
2. Remove front squawker mounting screws.
3. Disconnect connector and remove front squawker.

Installation is the reverse order of removal.

Scheme 55

1. Remove luggage side finisher upper. Refer to «EXPLODED VIEW»(ref-368866-S24903155152010081300000) .
2. Remove rear squawker mounting screws.
3. Remove rear squawker.

Installation is the reverse order of removal.

Scheme 56

1. Remove center speaker grille. Refer to «EXPLODED VIEW»(ref-368874-S28263366332010081300000) .
2. Remove center speaker mounting screws, lift up the center speaker and disconnect connector.
3. Remove center speaker.

Installation is the reverse order of removal.

Scheme 57

1. Pull up luggage finisher cover and hang the strap to upper body.
2. Remove woofer clamp.
3. Remove harness clip and connector.
4. Remove woofer.

Installation is the reverse order of removal.

Scheme 58

Scheme 59

1. Remove luggage floor spacer (LH). Refer to «EXPLODED VIEW»(ref-368866-S24903155152010081300000) .
2. Remove BOSE amp. mounting nuts.
3. Disconnect connector and remove BOSE amp.

Installation is the reverse order of removal.

Scheme 60

Scheme 61

1. Remove luggage floor spacer (RH). Refer to «EXPLODED VIEW»(ref-368866-S24903155152010081300000) .
2. Remove nuts, and then satellite radio tuner connector and TEL adapter unit connector.
3. Remove satellite radio tuner (1) with TEL adapter unit (2) as a single unit from the body.

Install in the reverse order of removal.

Scheme 62

Refer to COMPONENTS for symbols above.

1. Remove headlining (rear). Keep a service area. Refer to «EXPLODED VIEW»(ref-368866-S40355630512010081300000) .
2. Remove antenna base mounting nut.
3. Disconnect connector and remove antenna base.

Installation is the reverse order of removal.

Antenna base mounting nut Torque Specifications: 6.5 N.m (0.66 kg-m, 58 in-lb)

Refer to EXPLODED VIEW .

Scheme 63

1. Remove cluster lid D. Refer to «EXPLODED VIEW»(ref-368874-S28263366332010081300000) .
2. Remove multifunction switch mounting screws.
3. Disconnect connector and remove multifunction switch.

Installation is the reverse order of removal.

Refer to EXPLODED VIEW .

Scheme 64

Scheme 65

1. Remove cluster lid C. Refer to «EXPLODED VIEW»(ref-368874-S28263366332010081300000) .
2. Remove preset switch mounting screws.
3. Remove preset switch.

Installation is the reverse order of removal.

Note. When installing preset switch, do not allow the print wire that connects preset switch and multifunction switch to get caught in between AV control unit and preset switch.

Scheme 66

1. Remove front display unit with bracket. Refer to «REMOVAL AND INSTALLATION»(ref-368887-S19032328622010081300000) .
2. Remove front display from display bracket.
3. Remove iPod adapter mounting screws.
4. Disconnect connector and remove iPod adapter.

Install in the reverse order of removal.

Scheme 67

1. Remove console box assembly. Refer to «EXPLODED VIEW»(ref-368874-S13926164262010081300000) .
2. Press pawl from the back of console finisher to remove iPod connector.

Install in the reverse order of removal.

Scheme 68

1. Remove console box assembly. Refer to «EXPLODED VIEW»(ref-368874-S13926164262010081300000) .
2. Remove auxiliary mounting screws.
3. Disconnect connector and remove auxiliary input jacks.

Installation is the reverse order of removal.

Refer to EXPLODED VIEW .

Scheme 69

Scheme 70

1. Remove map lamp assembly. Refer to «EXPLODED VIEW»(ref-368866-S40355630512010081300000) .
2. Remove microphone (1), stretching pawls of map lamp assembly.

Installation is the reverse order of removal.

Scheme 71

1. Remove front seat (LH side). Refer to «EXPLODED VIEW»(ref-368879-S29550292862010081300000) .
2. Remove floor carpet. Keep a service area.
3. Remove camera control unit mounting screws.
4. Disconnect connector and remove camera control unit.

1. Installation is the reverse order of removal.
2. Perform predicted course line center position adjustment. Refer to «PREDICTED COURSE LINE CENTER POSITION ADJUSTMENT: SPECIAL REPAIR REQUIREMENT»(ref-368887-S24387538072010081300000) .

Scheme 72

1. Remove back door outside finisher upper. Refer to «EXPLODED VIEW»(ref-368865-S25889206792010081300000) .
2. Remove door handle cover. Refer to «EXPLODED VIEW»(ref-368865-S25889206792010081300000) .
3. Remove rear view camera mounting screws and rear view camera harness connector.
4. Remove rear view camera.

1. Installation is the reverse order of removal.
2. Adjust the guide line position if the guide line position is shifted after installing the rear view camera. Refer to «ADJUSTMENT»(ref-368887-S40745003162010081300000) .

Scheme 73

Scheme 74

1. Draw lines on rearward area of the vehicle passing through the following points: 250 mm (9.84 in) from both sides of the vehicle, and 0.5 m (1.64 ft), 1.0 m (3.28 ft) from the rear end of the bumper.
2. Set into "Adjust offset of rear view camera" mode of Confirmation/Adjustment mode.
3. Rotate the center dial, and then select the guiding line pattern so that its angle is aligned with the correction line of the rear of the vehicle. Selected pattern: 7
4. Fine adjust the guiding line so that its position is aligned to the correction line by pressing the up/down/left/right switches. Pressing "ENTER" enable the camera control unit to memory the adjusted guiding line position. Up/Down adjustment range: -20 - 20 Left/Right adjustment range: -20 - 20 CAUTION: Never operate other function such as pressing BACK while writing index data. If Confirmation/Adjustment mode does not function in the above procedure, perform one of the following service to adjust the index again. Remove battery for five min. Then reconnect battery. Remove camera control unit connector for five min. Then reconnect camera control unit connector.

Scheme 75

Scheme 76

1. Remove luggage floor spacer (RH). Refer to «EXPLODED VIEW»(ref-368866-S24903155152010081300000) .
2. Remove nuts, and then remove TEL adapter unit connector and satellite radio tuner connector.
3. Remove TEL adapter unit (1) with satellite radio tuner (2) as a single unit from the body.

Install in the reverse order of removal.

Refer to EXPLODED VIEW .

Scheme 77

1. Remove spiral cable. Refer to «EXPLODED VIEW»(ref-368845-S14581972892010081300000) .
2. Remove steering angle sensor mounting screws.
3. Remove steering angle sensor.

Installation is the reverse order of removal.

Scheme 78
