Scheme 2
OPERATION PROCEDURE
- Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
- Turn the push-button ignition switch to ACC position. (At this time, the steering lock will be released.
- Disconnect both battery cables. The steering lock will remain released with both battery cables disconnected and the steering wheel can be turned.
- Perform the necessary repair operation.
- When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn the push-button ignition switch from ACC position to ON position, then to LOCK position. The steering wheel will lock when the push-button ignition switch is turned to LOCK position.
- Perform self-diagnosis check of all control units using CONSULT-III.
Description
| Selection points | Selection parts | Selection items | Selection methods |
|---|---|---|---|
| Between cylinder block and crankshaft | Main bearing | Main bearing grade (bearing thickness) | Determined by match of cylinder block bearing housing grade (inner diameter of housing) and crankshaft journal grade (outer diameter of journal) |
| Between crankshaft and connecting rod | Connecting rod bearing | Connecting rod bearing grade (bearing thickness) | Determined by match of connecting rod big end diameter grade (inner diameter of housing) and crankshaft pin outer diameter. |
| Between cylinder block and piston | Piston and piston pin assembly. Piston is available together with piston pin as assembly. | Piston grade (piston skirt diameter) | Piston grade = cylinder bore grade (inner diameter of bore) |
SELECTION METHODS TABLE
- The identification grade stamped on each part is the grade for the dimension measured in new condition. This grade cannot apply to reused parts.
- For reused or repaired parts, measure the dimension accurately. Determine the grade by comparing the measurement with the values of each selection table.
- For details of the measurement method of each part, the reuse standards and the selection method of the selective fitting parts, refer to the text.
