Ipdm E/r: Removal & Installation Infiniti FX50 II

Body Electrical 2 illustrations

Removal and Installation

CAUTION

IPDM E/R integrated relays are not serviceable parts, and must not be removed from the unit.

Scheme 138

Scheme 138: REMOVAL

Scheme 138: REMOVAL

Scheme 139

Scheme 139

Scheme 139

Disconnect the battery cable from the negative terminal.
Remove the cowl top cover (RH). Refer to «EXPLODED VIEW»(ref-368865-S39437057562010081300000) .
Pull up the IPDM E/R assembly while pressing the pawls (A) on the back of the IPDM E/R cover B (1).
Remove the IPDM E/R cover A (1) while pressing the pawls (A) at the lower end of the IPDM E/R cover A.
Disconnect the harness connector and remove the IPDM E/R (2).
Remove the IPDM E/R cover B.

INSTALLATION

Install in the reverse order of removal.
