Automatic HVAC System 4 illustrations ~334 words

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SRS AIRBAG - FX35_FX50 and SEAT BELTS - FX35_FX50 .

WARNINGTo avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see SRS AIRBAG . Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

Precaution Necessary for Steering Wheel Rotation after Battery Disconnect

Note. Before removing and installing any control units, first turn the push-button ignition switch to the LOCK position, then disconnect both battery cables. After finishing work, confirm that all control unit connectors are connected properly, then re-connect both battery cables. Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work. If a DTC is detected, perform trouble diagnosis according to self-diagnosis results.

This vehicle is equipped with a push-button ignition switch and a steering lock unit.

If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.

If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure below before starting the repair operation.

Precaution For Procedure Without Cowl Top Cover

When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc.

Scheme 274

Scheme 274: Precaution For Procedure Without Cowl Top Cover

Commercial Service Tool

COMMERCIAL SERVICE TOOL REFERENCE Tool name Description Power tool For loosening bolts and nuts Remover tool Remove clips, pawls, metal clips

Scheme 275

Scheme 275: Commercial Service Tool

Scheme 276

Scheme 276: Exploded View

Scheme 277

Scheme 277: REMOVAL
  1. Remove instrument lower panel RH. Refer to «EXPLODED VIEW»(ref-368874-S28263366332010081300000) .
  2. Remove filter cover (1), and then remove in-cabin microfilter (2).
