The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the article. SUPPLEMENTAL RESTRAINT SYSTEM and SEAT BELTS .
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SUPPLEMENTAL RESTRAINT SYSTEM . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this article. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
Scheme 49
Scheme 50
- Before connecting or disconnecting the AWD control unit harness connector, turn ignition switch "OFF" and disconnect battery ground cable. Because battery voltage is applied to AWD control unit even if ignition switch is turned "OFF".
- When connecting or disconnecting pin connectors into or from AWD control unit, take care not to damage pin terminals (bend or break). When connecting pin connectors, make sure that there are no bends or breaks on AWD control unit pin terminal.
- Before replacing AWD control unit, perform AWD control unit input/output signal inspection and make sure whether AWD control unit functions properly or not. Refer to " «AWD CONTROL UNIT INPUT/OUTPUT SIGNAL REFERENCE VALUES»(ref-282575-S16757977342008040500000) ".
Scheme 51
Service Notice or Precautions
- Do not reuse transfer fluid, once it has been drained.
- Check the fluid level or replace the fluid only with the vehicle parked on level ground.
- During removal or installation, keep inside of transfer clear of dust or dirt.
- Replace all tires at the same time. Always use tires of the proper size and the same brand and pattern. Fitting improper size and unusual wear tires applies excessive force to vehicle mechanism and can cause longitudinal vibration.
- Disassembly should be done in a clean work area, it is preferable to work in dustproof area.
- Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the internal parts from becoming contaminated by dirt or other foreign matter.
- All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or reassembly.
- Check for the correct installation status prior to removal or disassembly. If matching marks are required, be certain they do not interfere with the function of the parts when applied.
- Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them with a new ones if necessary.
- Gaskets, seals and O-rings should be replaced any time when the transfer is disassembled.
- In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If tightening sequence is specified, use it.
- Observe the specified torque when assembling.
- Clean and flush the parts sufficiently and blow-dry them.
- Be careful not to damage sliding surfaces and mating surfaces.
- Clean inner parts with lint-free cloth or towels. Do not use cotton work gloves and rags to prevent adhering fibers.
Special Service Tools
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
SPECIAL SERVICE TOOLS CHART Tool number (Kent-Moore No.) Tool name Description ST27862000 ( - ) Drift 62.5 mm (2.461 in) dia. 42 mm (1.65 in) dia. Installing front oil seal KV381054S0 (J-34286) Puller Removing rear oil seal ST30720000 (J-25405) Drift 77 mm (3.03 in) dia. 55.5 mm (2.185 in) dia. Installing rear oil seal Installing mainshaft oil seal KV40104830 ( - ) Drift 70 mm (2.76 in) dia. 63.5 mm (2.500 in) dia. Installing rear oil seal KV38100300 (J-25523) Drift 54 mm (2.13 in) dia. 46 mm (1.81 in) dia. 32 mm (1.26 in) dia. Removing mainshaft bearing ST33052000 ( - ) Drift 28 mm (1.10 in) dia. 22 mm (0.87 in) dia. Removing mainshaft assembly ST30611000 (J-25742-1) Drift bar 350 mm (1.10 in) 25 mm (1.10 in) dia. M12 x 1.5P Removing rear bearing ST35321000 ( - ) Drift 49 mm (1.93 in) dia. 41 mm (1.61 in) dia. Removing rear bearing Installing mainshaft assembly ST31214000 (J-25269-B) Drift 34 mm (1.34 in) dia. 25.5 mm (1.004 in) dia. Removing front drive shaft front bearing Removing front drive shaft rear bearing KV38104010 ( - ) Drift 67 mm (2.64 in) dia. 49 mm (1.93 in) dia. Installing front drive shaft rear bearing Installing rear bearing ST33200000 (J-26082) Drift 60 mm (2.36 in) dia. 44.5 mm (1.752 in) dia. Installing front drive shaft front bearing ST30621000 (J-25742-5) Drift 80 mm (3.15 in) dia. 59 mm (2.32 in) dia. Installing mainshaft bearing
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Commercial Service Tools
COMMERCIAL SERVICE TOOLS CHART Tool name Description Puller Removing companion flange Flange wrench Removing and installing self-lock nut Puller Removing front drive shaft front bearing Removing front drive shaft rear bearing Power tool Loosening bolts and nuts
Scheme 60
Scheme 61
Scheme 62
AWD CONTROL UNIT
- Controls distribution of drive power between rear-wheel drive (0:100) and AWD (50:50) conditions according to signals from sensors.
- Self-diagnosis can be done with CONSULT-II.
Scheme 63
AWD WARNING LAMP
Turns ON when there is a malfunction in AWD system. It indicates that fail-safe mode is engaged and vehicle change to rear-wheel drive or shifting driving force-AWD (Front-wheels still have some driving torque).
Also turns ON when ignition switch is turned ON, for purpose of lamp check. Turns OFF approximately for 1 seconds after the engine starts if system is normal.
AWD Warning Lamp Indication
| Condition | AWD warning lamp |
|---|---|
| Lamp check | Turns ON when ignition switch is turned ON. Turns OFF approx. 1 second after engine start. |
| AWD system malfunction | ON |
| Protection function is activated due to heavy load to electric controlled coupling. (AWD system is not malfunctioning and AWD system changes to 2WD mode.) | Rapid flashing: 2 times/second (Flashing in approx. 1 minute and then turning OFF.) |
| Large difference in diameter of front/rear tires | Slow flashing: 1 time/2 seconds (Continuing to flash until turning ignition switch OFF) |
| Other than above (system normal) | OFF |
AWD WARNING LAMP INDICATION REFERENCE CHART
Scheme 64
FUNCTION
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
| Diagnostic test mode | Function | Reference |
|---|---|---|
| Self-diagnostic results | Self-diagnostic results can be read and erased quickly. | SELF-DIAG RESULT MODE |
| Data monitor | Input/Output data in the AWD control unit can be read. | DATA MONITOR MODE |
| CAN diagnostic support monitor | The results of transmit/receive diagnosis of CAN communication can be read. | CAN DIAGNOSTIC SUPPORT MONITOR |
| Active test | Diagnostic Test Mode in which CONSULT-II drives some actuators apart from the AWD control unit and also shifts some parameters in a specified range. | ACTIVE TEST MODE |
| ECU part number | AWD control unit part number can be read. | AWD CONTROL UNIT PART NUMBER |
CONSULT-II FUNCTION CHART
CONSULT-II SETTING PROCEDURE
Refer to " CONSULT-II START PROCEDURE ".
Scheme 65
- Perform "CONSULT-II Start Procedure". Refer to " «CONSULT-II START PROCEDURE»(ref-282577-S13463435832008040500000) ".
- Start engine and drive at 30 km/h (19 MPH) or more for approx. 1 minute.
- Stop vehicle. With engine at idle, touch "SELF-DIAG RESULTS". Display shows malfunction experienced since the last erasing operation. NOTE: The details for "TIME" are as follow: "0": Error currently detected with AWD control unit. Except for "0": Error detected in the past and memorized with AWD control unit. Detects frequency of driving after DTC occurs (frequency of turning ignition switch "ON").
Display Item List
| Items (CONSULT-II screen terms) | Diagnostic item is detected when... | Check item |
|---|---|---|
| CONTROLLER FAILURE [C1201] | Malfunction has occurred inside AWD control unit. | " AWD CONTROL UNIT " |
| ABS SYSTEM [C1203] | Malfunction related to wheel sensor has been detected by ABS actuator and electric unit (control unit). | " ABS SYSTEM " |
| 4WD SOLENOID [C1204] | Malfunction related to AWD solenoid has been detected. | " AWD SOLENOID " |
| 4WD ACTUATOR RLY [C1205] | Malfunction has been detected from AWD actuator relay integrated with AWD control unit, or malfunction related to AWD solenoid has been detected. | " AWD ACTUATOR RELAY " or " AWD SOLENOID " |
| ENGINE SIGNAL 1 [C1210] | Malfunction has been detected from ECM. | " ENGINE CONTROL SIGNAL " |
| CAN COMM CIRCUIT [U1000] | When AWD control unit is not transmitting or receiving CAN communication signal for 2 seconds or more. | " CAN COMMUNICATION LINE " |
| NO DTC IS DETECTED. FURTHER TESTING MAY BE REQUIRED. | No NG item has been detected. |
DISPLAY ITEM LIST
| CAUTION | If "CAN COMM CIRCUIT [U1000]" is displayed with other DTCs, first perform the trouble diagnosis for CAN communication line. Make sure that ABS warning lamp turns OFF by driving for a minute at vehicle speed of 30 km/h (19 MPH) or more after turning ignition switch "OFF" if AWD warning lamp turns ON with system malfunction of "ABS SYSTEM [C1203]". AWD warning lamp may not turn OFF if it is normal unless ignition switch turns OFF at once and engine restarts after that. |
| Monitored item (Unit) | Monitor item selection | Remarks | ||
|---|---|---|---|---|
| ECU INPUT SIGNALS | MAIN SIGNALS | SELECTION FROM MENU | ||
| X: Standard -: Not applicable | ||||
| FR RH SENSOR (km/h) or (mph) | X | X | X | Wheel speed calculated by front wheel sensor RH signal is displayed. |
| FR LH SENSOR (km/h) or (mph) | X | X | X | Wheel speed calculated by front wheel sensor LH signal is displayed. |
| RR RH SENSOR (km/h) or (mph) | X | X | X | Wheel speed calculated by rear wheel sensor RH signal is displayed. |
| RR LH SENSOR (km/h) or (mph) | X | X | X | Wheel speed calculated by rear wheel sensor LH signal is displayed. |
| BATTERY VOLT (V) | X | Power supply voltage for AWD control unit | ||
| THRTL POS SEN (%) | X | Throttle opening status is displayed. | ||
| ETS SOLENOID (A) | X | Monitored value of current at AWD solenoid | ||
| STOP LAMP SW (ON/OFF) | X | Stop lamp switch signal status via CAN communication line is displayed. | ||
| ENG SPEED SIG (RUN/STOP) | X | Engine status is displayed. | ||
| ETS ACTUATOR (ON/OFF) | X | Operating condition of AWD actuator relay (integrated in AWD control unit) is displayed. | ||
| 4WD WARN LAMP (ON/OFF) | X | Control status of AWD warning lamp is displayed. | ||
| 4WD MODE SW (AUTO) | X | AWD lock switch is not equipped, but displayed. | ||
| 4WD MODE MON (AUTO) | X | Control status of AWD is displayed. | ||
| DIS-TIRE MONI (mm) | X | Improper size tire installed condition is displayed. | ||
| P BRAKE SW (ON/OFF) | X | Parking switch signal status via CAN communication line is displayed. | ||
| Voltage (V) | X | The value measured by the voltage probe is displayed | ||
| Frequency (Hz) | X | The value measured by the pulse probe is displayed. | ||
| DUTY-HI (high) (%) | X | |||
| DUTY-LOW (low) (%) | X | |||
| PLS WIDTH-HI (msec) | X | |||
| PLS WIDTH-LOW (msec) | X | |||
DISPLAY ITEM LIST
AWD CONTROL UNIT PART NUMBER
Ignore the AWD control unit part number displayed in the "ECU PART NUMBER".
Refer to parts catalog to order the AWD control unit.
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
| Monitored item [Unit] | Condition | Display value (Approx.) |
|---|---|---|
| BATTERY VOLT [V] | Ignition switch: ON | Battery voltage |
BATTERY VOLTAGE REFERENCE CHART
Scheme 66
Scheme 67
Scheme 68
- CHECK POWER SUPPLY Turn ignition switch "OFF". Disconnect AWD control unit harness connector. Turn ignition switch "ON". (Do not start engine.) Check voltage between AWD control unit harness connector terminals and ground. TERMINAL VOLTAGE REFERENCE CHART Connector Terminal Voltage (Approx.) M92 7 - Ground Battery voltage 9 - Ground Turn ignition switch "OFF". Check voltage between AWD control unit harness connector terminals and ground. TERMINAL VOLTAGE REFERENCE CHART Connector Terminal Voltage (Approx.) M92 7 - Ground 0V 9 - Ground Battery voltage OK or NG OK: GO TO 2 . NG: Check the following. If any items are damaged, repair or replace damaged parts. 10A fuse [No. 12 or 21, located in the fuse block (J/B)] Harness for short or open between battery and AWD control unit harness connector terminal 9 Harness for short or open between ignition switch and AWD control unit harness connector terminal 7 Ignition switch. Refer to " «POWER SUPPLY ROUTING CIRCUIT»(ref-282579-S38730370472008040500000) ".
- CHECK GROUND CIRCUIT Turn ignition switch "OFF" Disconnect AWD control unit harness connector. Check continuity between AWD control unit harness connector M92 terminals 10, 11 and ground. Continuity should exist. Also check harness for short to ground and short to power. OK or NG OK: GO TO 3 . NG: Repair open circuit or short to ground or short to power in harness or connectors.
- CHECK DTC Start engine. Does AWD warning lamp turn OFF? Yes: INSPECTION END No: Perform the self-diagnosis, repair or replace damaged parts. Refer to " «SELF-DIAG RESULT MODE»(ref-282575-S03553396562008040500000) ".
Data are reference value.
| Monitored item [Unit] | Condition | Display value | |
|---|---|---|---|
| ETS SOLENOID [A] | Engine running | At idle speed | Approx. 0.000A |
| When depressing accelerator pedal | Approx. 0.000 - 2.400A (1) | ||
| (1) The values are changed by throttle opening and engine speed. | |||
| (1) | The values are changed by throttle opening and engine speed. |
MONITORED ITEM REFERENCE CHART
Data are reference value.
| Monitored item | Condition | Display value |
|---|---|---|
| ETS ACTUATOR [ON/OFF] | Engine stopped (Ignition switch: ON) | OFF |
| Engine running | ON |
MONITORED ITEM REFERENCE CHART
While Driving, AWD Warning Lamp Flashes Rapidly (When Flashing in Approx. 1 Minute and Then Turning OFF)
Note. Rapid flashing: 2 times/second
This symptom protects drivetrain parts when a heavy load is applied to the electric controlled coupling and multiple disc clutch temperature increases. Also, optional distribution of torque sometimes becomes rigid before lamp flashes rapidly. Both cases are not malfunction.
When this symptom occurs, stop vehicle and allow it to idle for some times. Flashing will stop and system will be restored.
While Driving, AWD Warning Lamp Flashes Slowly (When Continuing to Flash until Turning Ignition Switch OFF)
Note. Slow flashing: 1 time/2 seconds
Scheme 69
- CHECK TIRE Check the following. Tire pressure Wear condition Longitudinal tire size (There is no difference between longitudinal tires.) OK or NG OK: GO TO 2 . NG: Drive at vehicle speed of 20 km/h (12 MPH) or more for 5 seconds or more after repairing or replacing damaged parts. (Initialize improper size tire information.)
- CHECK INPUT SIGNAL OF TIRE DIAMETER With CONSULT-II Start engine. Drive at 20 km/h (12 MPH) or more for approx. 200 seconds. Select "DATA MONITOR" mode for "ALL MODE AWD/4WD" with CONSULT-II. Check monitor "DIS-TIRE MONI". Display of "DIS-TIRE MONI" "0-4mm">>INSPECTION END Except for "0-4mm">>GO TO 3 .
- CHECK AWD CONTROL UNIT Check AWD control unit input/output signal. Refer to " «AWD CONTROL UNIT INPUT/OUTPUT SIGNAL REFERENCE VALUES»(ref-282575-S16757977342008040500000) ". OK or NG OK: GO TO 4 . NG: Check AWD control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
- SYMPTOM CHECK Check again. OK or NG OK: INSPECTION END NG: Replace AWD control unit.
Scheme 70
- Remove the dash side finisher. Refer to " «DASH SIDE FINISHER»(ref-282584-S39140048842008040500000) ".
- Disconnect AWD control unit connector.
- Remove the AWD control unit.
Cases
Check items below. If necessary, replace them with new ones.
- Contact surfaces of bearing for wear, damage, etc.
- Damage and cracks of case.
Scheme 71
Bearing
Check items below. If necessary, replace them with new ones.
- Damage and rough rotation of bearing.
Scheme 72
Shaft
Check items below. If necessary, replace them with new one.
- Damage, peeling, dent, uneven wear, bending, etc. of shaft.
Scheme 73
Gears and Chain
Check items below. If necessary, replace them with new ones.
- Excessive wear, damage, peeling, etc. of gear and chain.
Scheme 74
Scheme 75
Scheme 76
Scheme 77
- Install front drive shaft front bearing, using drifts. Tool number : ST33200000 (J-26082)
- Install front drive shaft rear bearing, using a drift. Tool number : KV38104010 ( - )
- Install drive chain to front drive shaft. CAUTION: Identification mark of drive chain should be in the side of front bearing of front drive shaft.
- Install drive chain to mainshaft, and then install tap front drive shaft with plastic hammer. Press-fit rear bearing of front drive shaft to rear case. CAUTION: Be careful not to tap drive chain.
- Install front case to rear case. Refer to " «FRONT CASE AND REAR CASE»(ref-282575-S17436730332008040500000) ".
Scheme 78
Scheme 79
- Install needle bearing to mainshaft. CAUTION: Apply ATF to periphery of needle bearing.
- Install sprocket and electric controlled coupling to mainshaft.
- Install spacer to main shaft.
- Install snap ring to mainshaft. CAUTION: Do not reuse snap ring.
- Install mainshaft assembly to rear case, then install front case and rear case. Refer to " «FRONT CASE AND REAR CASE»(ref-282575-S17436730332008040500000) ".
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
Scheme 91
- Install breather tube, with plastic hammer. CAUTION: Pay attention to the direction of breather tube.
- Install baffle plate to rear case, and tighten bolt to the specified torque. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ".
- Install rear bearing to rear case, using a drift. Tool number : KV38104010 ( - ) CAUTION: Apply ATF to inside of rear bearing.
- Install snap ring to rear case. CAUTION: Do not reuse snap ring.
- Install mainshaft assembly to rear case, using a drift. Tool number : ST35321000 ( - ) CAUTION: ATF should be applied to contact surface of mainshaft and rear bearing.
- Install O-ring to transfer assembly harness connector. CAUTION: Do not reuse O-ring. Apply ATF to O-ring.
- Install transfer assembly harness connector into rear case.
- Install retainer to transfer assembly harness connector.
- Set temperature sensor and tighten bolt to the specified torque. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ".
- Hold electric controlled coupling harness with oil cover hold plate, install oil cover to rear case, and tighten bolt to the specified torque. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ". CAUTION: The harness should be guided by a cut portion.
- Install oil gutter to rear case. CAUTION: The tip of oil gutter should be put into rear case groove.
- Install drive chain to front drive shaft. CAUTION: Identification mark of drive chain should be in the side of front bearing of front drive shaft.
- Install drive chain to mainshaft, and then install tap front drive shaft with plastic hammer. Press-fit rear bearing of front drive shaft to rear case. CAUTION: Be careful not to tap drive chain.
- Install mainshaft bearing to front case, using a drift. Tool number : ST30621000 (J-25742-5)
- Install snap ring to front case. CAUTION: Do not reuse snap ring.
- Apply liquid gasket to mating surface of rear case. Use Genuine Anaerobic Liquid Gasket or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-282577-S09389354212008040500000) ". CAUTION: Remove old sealant adhering to mounting surfaces. Also remove any moisture, oil, or foreign material adhering to application and mounting surfaces.
- Set front case to rear case. CAUTION: Be careful not to damage the mating surface transmission side.
- Tighten front case and rear case fixing bolts to the specified torque. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ". BOLT SPECIFICATION CHART Bolts symbol Quantity Bolt length " l " mm (in) A 11 42 (1.65) B 1 162 (6.38) C 1 97 (3.82) TORX bolts 1 40 (1.57)
- Install spacer to mainshaft. CAUTION: Apply ATF to spacer.
- Install rear oil seal to rear case, using a drift. Dimension A : 6.7 - 7.3 mm (0.264 - 0.287 in) Tool number A: ST30720000 (J-25405) B: KV40104830 ( - ) CAUTION: Do not reuse rear oil seal. Apply ATF to rear oil seal. When installing, do not incline rear oil seal.
- Install companion flange while align the matching mark of mainshaft with the mark of companion flange.
- Tighten self-lock nut to the specified torque, with flange wrench. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ". CAUTION: Do not reuse self-lock nut.
- Install mainshaft oil seal until it is flush with end face of front case, using drift. Tool number : ST30720000 (J-25405) CAUTION: Do not reuse mainshaft oil seal. Apply ATF to mainshaft oil seal. When installing, do not incline mainshaft oil seal.
- Install front oil seal until it is flush with end face of front case, using drift. Tool number : ST27862000 ( - ) CAUTION: Do not reuse front oil seal. Apply ATF to front oil seal. When installing, do not incline front oil seal.
- Apply sealant to threads of drain plug. Then install it to rear case and tighten to the specified torque. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ". Use Genuine Silicone RTV or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-282577-S09389354212008040500000) ". CAUTION: Remove old sealant and oil adhering to threads.
- Set gasket to filler plug. Install it to rear case and tighten to the specified torque. Refer to " «COMPONENTS»(ref-282575-S26065640662008040500000) ".
| CAUTION | Do not reuse gasket. |
