Driver Information System: Overview Infiniti FX45 I рестайлинг

System Description

1. For the unified meter and A/C amp., the signal required for controlling the combination meter are integrated in the A/C auto amp.
2. The unified meter and A/C amp. corresponds to a CONSULT-II function (self-diagnosis results, CAN diagnosis support monitor, data monitor).

CONSULT-II BASIC OPERATION

Refer to " CONSULT-II START PROCEDURE ".

Operation Procedure

1. Touch "SELF-DIAG RESULTS" on "SELECT DIAG MODE" screen.
2. Self-diagnosis results are displayed.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch either "MAIN SIGNALS" or "SELECTION FROM MENU" on the "DATA MONITOR" screen. DATA MONITOR VALUES MAIN SIGNALS Monitors main signals. SELECTION FROM MENU Selects and monitors individual signal.
3. When "SELECTION FROM MENU" is selected, touch individual items to be monitored. When "MAIN SIGNALS" is selected, main items will be monitored.
4. Touch "START".
5. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

A/T shift position is displayed in the segment display in the combination meter.

1. Buzzer for warning chime system is installed in the combination meter.
2. The buzzer sounds when the combination meter receives buzzer output signal from each unit through unified meter and A/C amp.

DIAGNOSIS ITEMS DESCRIPTION

DIAGNOSIS ITEMS DESCRIPTION

Refer to " CONSULT-II START PROCEDURE ".

1. Touch "BUZZER" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch "ALL SIGNALS" or "SELECTION FROM MENU" on "DATA MONITOR" screen. DATA MONITOR VALUES ALL SIGNALS Monitors all items. SELECTION FROM MENU Selects and monitors items.
4. If "SELECTION FROM MENU" is selected, touch the desired monitor item. If "ALL SIGNALS" is selected, all items required to control are monitored.
5. Touch "START".
6. During monitoring, touching "RECORD" can start recording the monitored item status.

1. Touch "BUZZER" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch the item to be tested, and check the operation.
4. During the operation check, touching "OFF" deactivates the operation.

1. Touch "BCM" on "SELECT TEST ITEM" screen.
2. Touch "SELF-DIAG RESULTS" on "SELECT DIAG MODE" screen.
3. Self-diagnosis results are displayed.

LDW SYSTEM OPERATION

1. The Lane Departure Warning (LDW) system warns the driver when the vehicle is traveling close to either the left or the right of the traveling lane.
2. The system monitors lane markers of the traveling lane using the LDW camera unit. When the LDW camera unit detects that the vehicle is traveling close to either the left or the right of the traveling lane, the LDW indicator lamp flashes and a chime sounds to alert the driver. NOTE: When activating turn signal, LDW system does not give a warning to the lane marker on the turn signal side.
3. The LDW system can be turned on or off by pushing the LDW switch. When the system is on, the LDW system ON indicator illuminates.
4. The LDW system has an automatic mode and manual mode.

In the automatic mode

1. LDW system automatically turns on, when the ignition switch is turned to the ON position.
2. LDW system ON indicator located on the LDW switch illuminates, indicating that the system is on.
3. To cancel LDW system, push the LDW switch to turn off LDW system ON indicator.
4. To turn on the system, push LDW switch again.

In the manual mode

1. LDW system is still off when the ignition switch is turned to the ON position.
2. The LDW switch must be pushed to turn on the system.

To the change modes

1. Push and hold LDW switch for more than 4 seconds, when LDW system ON indicator is off.
2. Then LDW chime sounds and blinking of LDW system ON indicator informs that the mode change is completed. Temporary disabled status at high temperature If the vehicle is parked in direct sunlight under high temperature conditions [approximately over 104°F (40°C)] and then started, the LDW system may sound a chime and cancel automatically. Then LDW system ON indicator will blink. When the interior temperature is reduced, the system will resume to operate automatically and the LDW system ON indicator illuminates.

Scheme 58

Scheme 59

Components Description

COMPONENTS DESCRIPTION

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

1. With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, and then turn ignition switch ON.
2. Start the engine, wait for at least 10 seconds, and touch "START (NISSAN BASED VHCL)".
3. Touch "LDW" on "SELECT SYSTEM" screen. If "LDW" is not displayed, go to " «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-282577-S32433700532008040500000) ".
4. Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.
5. Touch "AUTO AIM" on "SELECT WORK ITEM" screen.
6. The target should be accurately placed. The vehicle should be stopped. After confirming the above, touch "START" to perform aiming. CAUTION: Never touch "START" when the target is not placed.
7. Touch "NEXT", then a keyboard window is displayed. And input "Dh", and then touch "ENTER". NOTE: Check the value "Dh". Refer to " «VEHICLE HEIGHT CHECK»(ref-282583-S01737669452008040500000) ".
8. Check the regulated value. (Spec.) NOTE: Check the value input at step 8. Touch "NEXT" if appropriate. Touch "CHANGE SET" to change "Dh".
9. Touch "NEXT". CAUTION: Never change "Ht".
10. Touch "NEXT". CAUTION: Never change "Dt".
11. Touch "START".
12. Check it display item. "NORMALLY COMPLETED" is displayed, then touching "COMPLETION". Perform the following services when displayed "SUSPENSION" or "ABNORMALLY COMPLETED". SERVICE PROCEDURE Displays item Service procedure SUSPENSION 00H Routine not activated Position the target appropriately again. Perform the aiming again. Refer to " «CAMERA AIMING ADJUSTMENT»(ref-282583-S09640622842008040500000) ". 10H Writing error ABNORMALLY COMPLETED - NOTE: Replace camera unit if "suspension" is repeatedly indicated though the above two service is performed.
13. Check if "NORMALLY COMPLETED" is displayed and close the aiming adjustment procedure by touching "END".

DESCRIPTION

CONSULT-II performs the following functions communicating with the LDW camera unit.

CONSULT-II FUNCTION (LDW)

Refer to " CONSULT-II START PROCEDURE ".

Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.

1. Touch "SELF-DIAG RESULTS" on "SELECT DIAG MODE" screen.
2. See the displayed result of self-diagnosis.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch any of "ALL SIGNALS" and "SELECTION FROM MENU" on selection screen.
3. Touch "START".
4. Display the data monitor.
5. If necessary, touch "COPY" in turn, and print data.

CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.

1. This electronic compass is able to display 8 primary directions: N, NE, E, SE, S, SW, W, NW.
2. The inside mirror switch (2) is used to operate the compass and automatic anti-glare system.

SYSTEM DESCRIPTION

Note. For further details of the compass and automatic anti-glare system, refer to Owner's service information

1. All standard compasses determine direction relative to Magnetic North; however, this electronic compass is designed to display direction relative to True North.
2. The difference between Magnetic North and True North varies from place to place across the surface of the earth.
3. This electronic compass must be "told" approximately where it is on the earth's surface so that the Magnetic North reading can be properly converted into a True North display.
4. To tell the electronic compass where it's at, the earth is separated into numbered "Zone Variances". The Zone Variance number in which the compass is to function must be entered into this electronic compass.
5. Each zone is magnetically about 4.2° wide. Typically, anything under 22.5° total zone change is not noticed on the electronic compass display. However, over 22.5°, a reading may be off by one or more primary directions.
6. On long trips, a vehicle may leave its original zone and enter one or more new zones. Generally, you do not need to reset the compass zone if you travel between 3 or 4 zones, such as business travel or vacation. The typical driver will not notice any difference on the display within 3 or 4 zones. However, if the vehicle is "permanently" moved to a new location, it is recommended that the compass zone be reset.

1. The rear view monitor is equipped to check the rearward of the vehicle with display when A/T selector lever is in reverse position.
2. The lines of vehicle sides and the distance from the rear end of the vehicle are provided on display as a guide. It allows the driver to know the distance between the vehicle and a rearward object, and the width of the vehicle much easier.

REAR VIEW CAMERA OPERATION

When A/T selector lever is reverse position, power is supplied

1. through back-up lamp relay terminal 2
2. to TCM terminal 7.

Then back-up lamp relay is energized

1. from back-up lamp relay terminal 5
2. to rear view camera control unit terminal 4.

Then, rear view camera control unit is sent camera ON signal

1. through rear view camera control unit terminal 8
2. to rear view camera terminal 1.

An image taken by rear view camera is sent

1. through rear view camera terminals 3 and 4
2. to rear view camera control unit terminals 10 and 9.

Then an image is sent

1. through rear view camera control unit terminals 12 and 14
2. to the display terminals 15 and 16.

An image of rear view will be projected on the display.

Refer to " CONSULT-II START PROCEDURE ".

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch either "SELCT GUIDELINE PATTERN" or "ADJ GUIDELINE POSITION" on the "WORK SUPPORT" screen.

SELCT GUIDELINE PATTERN

Refer to " SIDE DISTANCE GUIDELINE CORRECTION PROCEDURE " for detail.

1. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
2. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on the "DATA MONITOR" screen. DATA MONITOR VALUES ALL SIGNALS Monitors all signals. SELECTION FROM MENU Selects and monitors individual signal.
3. When "SELECTION FROM MENU" is selected, touch individual items to be monitored. When "ALL SIGNALS" is selected, all items will be monitored.
4. Touch "START".
5. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".
