CONSULT-II BASIC OPERATION
| CAUTION | If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be detected in self-diagnosis depending on control unit which carry out CAN communication. |
Scheme 16
Scheme 17
Scheme 18
Scheme 19
- With ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
- Touch "START (NISSAN BASED VHCL)".
- Touch "BCM" on "SELECT SYSTEM" screen. If "BCM" is not indicated, go to GI-39, "CONSULT-II Data Link Connector (DLC) Circuit".
- Touch "COMB SW".
Operation Procedure
- Touch "COMB SW" on "SELECT TEST ITEM" screen.
- Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
- Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "DATA MONITOR" screen. Consult-II Display ALL SIGNALS Monitors all the signals. SELECTION FROM MENU Selects and monitors individual signal.
- Touch "START".
- When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is selected, all the signals will be monitored.
- Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".
