Coil
Check coil for loose connection or cracked insulation.
Scheme 271
Scheme 272
Scheme 273
Scheme 274
- Install the field coil. Be sure to align the coil's pin with the hole in the compressor's front head.
- Install the field coil harness clip using a screwdriver.
- Install the pulley assembly using the installer and a hand press, and then install the snap ring using snap ring pliers.
- Install the clutch disc on the drive shaft, together with the original shim(s). Press the clutch disc down by hand.
- Using the holder to prevent clutch disc rotation, tighten the bolt to 14 N.m (1.4 kg-m, 10 ft-lb) torque. After tightening the bolt, make sure the pulley rotates smoothly.
- Check clearance around the entire periphery of clutch disc. Disc to pulley clearance : 0.25 - 0.6 mm (0.010 - 0.024 in) If the specified clearance is not obtained, replace adjusting spacer and readjust.
