Ventilation System: Removal & Installation Infiniti FX35 II рестайлинг

INSTALLATION

Install in the reverse order of removal.

Replacement

Replace in-cabin microfilter or air conditioner filter.

Refer to " FOR NORTH AMERICA: SCHEDULE 1 " and " FOR NORTH AMERICA: SCHEDULE 2 ".

Affix a caution label inside the glove box when replacing filter.

Scheme 237

Scheme 238

Scheme 239

1. Remove cluster lid D. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing screw (A).
3. Disengage fixing pawls, and then remove center ventilator grille (1).

Install in the reverse order of removal.

REMOVAL

Driver Side

Scheme 240

1. Remove ventilator duct LH. Refer to " «EXPLODED VIEW»(ref-524044-S34394366202013012500000) ".
2. Remove fixing screws (A), and then remove side ventilator grille LH (1).

Passenger Side

Scheme 241

1. Remove ventilator duct RH. Refer to " «EXPLODED VIEW»(ref-524044-S34394366202013012500000) ".
2. Remove fixing screws (A).
3. Remove harness fixing clip (B), and then remove side ventilator grille RH (1).

Install in the reverse order of removal.

Remove front defroster grilles (1), using a remover tool (A).

Scheme 242

Install in the reverse order of removal.

Remove side defroster grille (1), using a remover tool (A).

Scheme 243

Install in the reverse order of removal.

Scheme 244

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing screws (A), and then remove ventilator duct LH (1) and RH (2).

Install in the reverse order of removal.

Scheme 245

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing screw (A), and then remove adaptor duct (1).

Install in the reverse order of removal.

Scheme 246

1. Remove side defroster nozzle LH and RH. Refer to " «EXPLODED VIEW»(ref-524044-S34394366202013012500000) ".
2. Remove defroster nozzle (1).

Install in the reverse order of removal.

Driver Side

Scheme 247

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing clip (A) and harness fixing clip (B), and then remove side defroster nozzle LH (1).

Passenger Side

Scheme 248

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing clip (A), and then remove side defroster nozzle RH (1).

Install in the reverse order of removal.

Scheme 249

1. Remove front pillar garnish. Refer to " «EXPLODED VIEW»(ref-524011-S14116372642013012500000) ".
2. Remove fixing screws (A), and then remove side defroster duct (1).

Install in the reverse order of removal.

Scheme 250

1. Remove console rear finisher. Refer to " «EXPLODED VIEW»(ref-524023-S26869316852013012500000) ".
2. Remove fixing screws (A).
3. Disengage fixing pawls, and then remove rear ventilator grille (1).

Install in the reverse order of removal.

Scheme 251

1. Remove center console assembly. Refer to " «EXPLODED VIEW»(ref-524023-S26869316852013012500000) ".
2. Remove fixing screws (A), and then remove rear ventilator duct 1 (1).

Install in the reverse order of removal.

Scheme 252

1. Remove console rear finisher. Refer to " «EXPLODED VIEW»(ref-524023-S26869316852013012500000) ".
2. Remove rear ventilator duct 2 (1).

Install in the reverse order of removal.

Driver Side

Disengage fixing pawls, and then remove foot grille LH (1).

Scheme 253

Passenger Side

Disengage fixing pawls, and then remove foot grille RH (1).

Scheme 254

Install in the reverse order of removal.

Driver Side

Scheme 255

1. Remove heater & cooling unit assembly. Refer to the following: Refer to " «EXPLODED VIEW»(ref-523992-S23488245072013012500000) ". (VQ35HR) Refer to " «EXPLODED VIEW»(ref-524022-S12026349692013012500000) ". (VK50VE)
2. Remove fixing screws (A), and then remove heater pipe cover (1).
3. Remove fixing screws (B), and then remove foot duct LH (2).

Passenger Side

Scheme 256

1. Set the temperature at full cold.
2. Disconnect the battery cable from the negative terminal.
3. Remove air mix door motor. Refer to " «EXPLODED VIEW»(ref-523994-S27384490262013012500000) ".
4. Remove mode door motor and links. Refer to " «EXPLODED VIEW»(ref-523994-S27384490262013012500000) ".
5. Remove fixing screws (A), and then remove evaporator cover (1).
6. Remove fixing screws (B), and then remove foot duct RH (2).

Install in the reverse order of removal.

Scheme 257

1. Remove instrument lower panel LH. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing screw (A), and then remove heater duct (1).

Install in the reverse order of removal.

Scheme 258

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove fixing clips (A), and then remove rear floor duct 1 (1).

Install in the reverse order of removal.

Scheme 259

Scheme 260

1. Remove instrument lower panel RH. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Disconnect AWD control unit connector. Refer to " «EXPLODED VIEW»(ref-524045-S30476678552013012500000) ".
3. Disconnect ECM (1) connectors.
4. Remove mounting nuts (A), and then remove ECM with bracket attached.
5. Remove power steering control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-524055-S36777057672013012500000) ".
6. Disconnect intake door motor connector and blower motor connector.
7. Remove mounting bolt (A) and fixing screw (B), and then remove blower unit assembly (1).

Scheme 261

Note the following item, and then install in the reverse order of removal

Scheme 262

Scheme 263

1. Remove instrument lower cover RH. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Disconnect blower motor connector.
3. Remove fixing screws (A), and then remove blower motor (1).

Install in the reverse order of removal.
