Automatic Drive Positioner: Removal & Installation Infiniti FX35 II

Seats 5 illustrations ~318 words

REMOVAL

CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.
  1. Remove the driver seat (1). Refer to " «REMOVAL AND INSTALLATION»(ref-337272-S19771903352009073100000) ".
  2. Remove the mounting bolts (A).
  3. Remove driver seat control unit (2).

Scheme 4

Scheme 4
Scheme 4

INSTALLATION

Install in the reverse order of removal.

CAUTIONBe sure to clump the harness to the right place.

Note. After installing the driver seat, perform additional service when replacing control unit. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : DESCRIPTION ".

CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.
  1. Remove the instrument driver lower panel. Refer to " «REMOVAL AND INSTALLATION»(ref-337259-S00059521812009073100000) ".
  2. Remove the screws (A).
  3. Remove automatic drive positioner control unit (1).

Scheme 5

Scheme 5
Scheme 5

Install in the reverse order of removal.

CAUTIONBe sure to clump the harness to the right place.

Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : DESCRIPTION ".

CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.
  1. Remove the front door finisher (1). Refer to " «REMOVAL AND INSTALLATION»(ref-337246-S30243974382009073100000) ".
  2. Press pawls and remove seat memory switch (2) from front door finisher (1).

Scheme 6

Scheme 6
Scheme 6

Install in the reverse order of removal.

CAUTIONBe sure to clump the harness to the right place.

Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : DESCRIPTION ".

CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.
  1. Remove the seat cushion outer finisher (1). Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-337272-S30985812222009073100000) ".
  2. Remove the screws (A).
  3. Remove the power seat switch (2) from the seat cushion outer finisher (1).

Scheme 7

Scheme 7
Scheme 7

Install in the reverse order of removal.

CAUTIONBe sure to clump the harness to the right place.

Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : DESCRIPTION ".

CAUTIONWhen removing and installing, use shop cloths to protect parts from damage.
  1. Remove the steering column mask (1). Refer to " «REMOVAL AND INSTALLATION»(ref-337259-S00059521812009073100000) ".
  2. Press pawls and remove tilt & telescopic switch (2) from the steering column mask (1).

Scheme 8

Scheme 8
Scheme 8

Install in the reverse order of removal.

CAUTIONBe sure to clump the harness to the right place.

Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : DESCRIPTION ".
