Mirrors (Without Adp): Removal & Installation Infiniti FX35 II

Mirrors 2 illustrations ~154 words

INSTALLATION

Install in the reverse order of removal.

Scheme 47: DOOR MIRROR ASSEMBLY : Exploded View

Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-337246-S30243974382009073100000) ".
Remove front door sash inner cover. Refer to " «EXPLODED VIEW»(ref-337302-S13347294342009073100000) ".
Disconnect door mirror harness connector.
Remove door mirror mounting nuts, and remove door mirror assembly.

Install in the reverse order of removal.

CAUTION

Perform camera image calibration. Refer to " CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR) : SPECIAL REPAIR REQUIREMENT ".

Scheme 48: DISASSEMBLY

Remove door mirror assembly. Refer to " «DOOR MIRROR ASSEMBLY : REMOVAL AND INSTALLATION»(ref-337300-S11627067332009073100000) ".
Remove glass mirror. Refer to " «GLASS MIRROR : DISASSEMBLY AND ASSEMBLY»(ref-337300-S21738126612009073100000) ".
Remove door mirror cover. Refer to " «DOOR MIRROR COVER : DISASSEMBLY AND ASSEMBLY»(ref-337300-S00334355562009073100000) ".
Remove screws (A) and connector, and then remove actuator (1).
Remove side camera and LED lamp. Refer to " «REMOVAL AND INSTALLATION»(ref-337295-S19331903272009073100000) " (SIDE CAMERA LH), " «REMOVAL AND INSTALLATION»(ref-337295-S07663886812009073100000) " (SIDE CAMERA RH).
Remove base cover and puddle lamp.

Install in the reverse order of removal.
