1. CHECK MAP LAMP CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "MAP LAMP-DR" or "MAP LAMP-AS" of TOTAL ILLUM C/U active test item. While operating the test items, check map lamps operation. ACTIVE TEST Test item Operation MAP LAMP-DR On Map lamp (driver side) ON Off OFF MAP LAMP-AS On Map lamp (passenger side) ON Off OFF Are the map lamps turned ON/OFF? YES: Map lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S00738247652009073100000) ".

1. CHECK PERSONAL LAMP CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "PERSONAL LAMP-RR" or "PERSONAL LAMP-RL" of TOTAL ILLUM C/U active test item. While operating the test items, check personal lamps operation. ACTIVE TEST Test item Operation PERSONAL LAMP-RR On Personal lamp (RH) ON Off OFF PERSONAL LAMP-RL On Personal lamp (LH) ON Off OFF Are the personal lamps turned ON/OFF? YES: Personal lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S11857885672009073100000) ".

1. CHECK CENTER CONSOLE INDIRECT ILLUMINATION CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "AMBIENCE LAMP" of TOTAL ILLUM C/U active test item. While operating the test items, check center console indirect illumination operation. ACTIVE TEST Test item Operation AMBIENCE LAMP On Center console indirect illumination ON Off OFF Is the center console indirect illumination turned ON/OFF? YES: Center console indirect illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S12425658102009073100000) ".

1. CHECK FOOT LAMP CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "FOOT LAMP" of TOTAL ILLUM C/U active test item. While operating the test items, check foot lamps operation. ACTIVE TEST Test item Operation FOOT LAMP On Foot lamps ON Off OFF Are the foot lamps turned ON/OFF? YES: Foot lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S37062498402009073100000) ".

1. CHECK PUDDLE LAMP CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "PUDDLE LAMP" of TOTAL ILLUM C/U active test item. While operating the test items, check puddle lamps operation. ACTIVE TEST Test item Operation PUDDLE LAMP On Puddle lamps ON Off OFF Are the puddle lamps turned ON/OFF? YES: Puddle lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S37062498402009073100000) ".

1. CHECK MOOD LAMP (FRONT DOOR ARMREST) CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "MOOD LAMP" of TOTAL ILLUM C/U active test item. While operating the test items, check mood lamp (front door armrest) operation. ACTIVE TEST Test item Operation MOOD LAMP On Mood lamp (front door armrest) ON Off OFF Are the mood lamps (front door armrest) turned ON/OFF? YES: Mood lamp (front door armrest) circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S37062498402009073100000) ".

1. CHECK PUSH-BUTTON IGNITION SWITCH ILLUMINATION OPERATION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "ENGINE SWITCH ILLUMINATION" of TOTAL ILLUM C/U active test item. While operating the test items, check the push-button ignition switch illumination operation. ACTIVE TEST Test item Operation ENGINE SWITCH ILLUMINATION On Push-button ignition switch illumination ON Off OFF Is the push-button ignition switch illumination turned ON/OFF? YES: Push-button ignition switch illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S31405218412009073100000) ".

1. CHECK MOOD LAMP (REAR DOOR ARMREST) CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "MOOD LAMP" of TOTAL ILLUM C/U active test item. While operating the test items, check mood lamp (rear door armrest) operation. ACTIVE TEST Test item Operation MOOD LAMP On Mood lamp (rear door armrest) ON Off OFF Are the mood lamps (rear door armrest) turned ON/OFF? YES: Mood lamp (rear door armrest) circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S37159918952009073100000) ".

1. CHECK ILLUMINATION CONTROL FUNCTION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "HSPL ILLUMINATION" of TOTAL ILLUM C/U active test item. While operating the test items, check the illuminations operation. ACTIVE TEST Test item Operation HSPL ILLUMINATION On Illuminations ON Off OFF Are the illuminations turned ON/OFF? YES: Hospitality illumination circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S41588109182009073100000) ".

1. CHECK STEP LAMP OPERATION CONSULT-III ACTIVE TEST Turn ignition switch ON. Select "STEP LAMP TEST" of BCM (INT LAMP) active test item. While operating the test items, check the step lamp operation. ACTIVE TEST Test item Operation STEP LAMP TEST On Step lamps ON Off OFF Are the step lamps turned ON/OFF? YES: Step lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S10745246472009073100000) ".

Note. Check the tail lamp circuit if the tail lamp is not turned ON. Refer to " COMPONENT FUNCTION CHECK ".

1. CHECK TAIL LAMP SIGNAL INPUT WITH CONSULT-III CONSULT-III DATA MONITOR Turn ignition switch ON. Select "TAIL LAMP SIGNAL" of TOTAL ILLUM C/U data monitor item. While operating the lighting switch, check the monitor status. MONITOR ITEM CHART Monitor item Condition Monitor status Lighting switch TAIL LAMP SIGNAL OFF Off 1ST On Is the measurement value normal? YES: Tail lamp signal circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S03641843152009073100000) ".

1. CHECK ILLUMINATION CONTROL SIGNAL INPUT BY CONSULT-III CONSULT-III DATA MONITOR Turn ignition switch ON. Switch the lighting switch 1ST. Select "ILLUM CONT SIGNAL" of TOTAL ILLUM C/U data monitor item. While operating the illumination control switch, check the monitor status. MONITOR ITEM CHART Monitor item Condition Monitor status ILLUM CONT SIGNAL Brightness level Maximum 100 % Midway 50 % Minimum 0 % Is the item status normal? YES: Illumination control signal circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S12925935312009073100000) ".

Scheme 42

1. CHECK ILLUMINATION CONTROL SIGNAL INPUT Switch the lighting switch 1ST. While operating the illumination control switch, check the voltage between the total illumination control unit harness connector and the ground. TERMINAL VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) Total illumination control unit Ground Brightness level Connector Terminal M129 24 Maximum 0 V Midway Minimum 8 V Is the measurement value normal? YES: Replace the total illumination control unit. NO: GO TO 2.
2. CHECK ILLUMINATION CONTROL SIGNAL CIRCUIT FOR OPEN Turn ignition switch OFF. Disconnect the total illumination control unit connector and the combination meter connector. Check continuity between the total illumination control unit harness connector and the combination meter harness connector. TERMINAL CONTINUITY REFERENCE Total illumination control unit Combination meter Continuity Connector Terminal Connector Terminal M129 24 M53 34 Existed Does continuity exist? YES: GO TO 3. NO: Repair the harnesses or connectors.
3. CHECK ILLUMINATION CONTROL SIGNAL SHORT CIRCUIT Disconnect the selector lever position indicator connector. Check continuity between the total illumination control unit harness connector and the ground. TERMINAL CONTINUITY REFERENCE Total illumination control unit Ground Continuity Connector Terminal M129 24 Not existed Does continuity exist? YES: Repair the harnesses or connectors. NO: Replace the total illumination control unit.

1. CHECK MAP LAMP SWITCH SIGNAL BY CONSULT-III CONSULT-III DATA MONITOR Turn ignition switch ON. Select "MAP LAMP SW" of TOTAL ILLUM C/U data monitor item. While operating the map lamp main switch, check the monitor status. MONITOR ITEM CHART Monitor item Condition Monitor status MAP LAMP SW Map lamp main switch DOOR Door ON All On OFF Off Is the item status normal? YES: Map lamp main switch circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S21990313852009073100000) ".

1. CHECK EACH DOOR SWITCH SIGNAL BY CONSULT-III CONSULT-III DATA MONITOR Turn ignition switch ON. Select "DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RR" and "DOOR SW-RL" of TOTAL ILLUM C/U data monitor item. While operating each door switch, check the monitor status. MONITOR ITEM CHART Monitor item Condition Monitor status DOOR-SW-DR Front door (driver side) Open On Close Off DOOR-SW-AS Front door (passenger side) Open On Close Off DOOR-SW-RR Rear door (RH) Open On Close Off DOOR-SW-RL Rear door (LH) Open On Close Off Is the item status normal? YES: Each door switch circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S19079375772009073100000) ".

Scheme 43

1. CHECK EACH DOOR SWITCH INPUT SIGNAL While operating each door switch, check the voltage between the total illumination control unit harness connector and the ground. Front door (driver side) TERMINAL VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) Total illumination control unit Ground Door Connector Terminal M129 29 Open 0 V Close 8.5 - 9.0 V Front door (passenger side) TERMINAL VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) Total illumination control unit Ground Door Connector Terminal M129 8 Open 0 V Close 8.5 - 9.0 V Rear door (LH) TERMINAL VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) Total illumination control unit Ground Door Connector Terminal M129 9 Open 0 V Close 8.5 - 9.0 V Rear door (RH) TERMINAL VOLTAGE REFERENCE Terminals Condition Voltage (Approx.) (+) (-) Total illumination control unit Ground Door Connector Terminal M129 25 Open 0 V Close 8.5 - 9.0 V Is the measurement value normal? Fixed at 8.5 - 9.5 V: Replace the total illumination control unit. Fixed at 0 V: GO TO 2.
2. CHECK TOTAL ILLUMINATION CONTROL UNIT (INTERNAL SHORT) Turn ignition switch OFF. Disconnect the total illumination control unit connector. Turn ignition switch ON. Check voltage between the total illumination control unit harness connector and ground. TERMINAL VOLTAGE REFERENCE Total illumination control unit Ground Voltage (Approx.) Connector Terminal Front door (driver side) M129 29 8.5 - 9.0 V Front door (passenger side) 8 Rear door (LH) 9 Rear door (RH) 25 Does continuity exist? YES: Replace the total illumination control unit. NO: GO TO 3.
3. CHECK EACH DOOR SWITCH SIGNAL CIRCUIT FOR OPEN Turn ignition switch OFF. Disconnect each door switch connector. Check continuity between the total illumination control unit harness connector and each door switch harness connector. TERMINAL CONTINUITY REFERENCE Total illumination control unit Door switch Continuity Connector Terminal Connector Terminal Front door (driver side) M129 29 B16 2 Existed Front door (passenger side) 8 B216 2 Rear door (LH) 9 B23 2 Rear door (RH) 25 B223 2 Does continuity exist? YES: GO TO 4. NO: Repair the harnesses or connectors.
4. CHECK EACH DOOR SWITCH SIGNAL CIRCUIT FOR SHORT Check continuity between total illumination control unit harness connector and ground. TERMINAL CONTINUITY REFERENCE Total illumination control unit Ground Continuity Connector Terminal Front door (driver side) M129 29 Not existed Front door (passenger side) 8 Rear door (LH) 9 Rear door (RH) 25 Does continuity exist? YES: Repair the harnesses or connectors. NO: Check each door switch. Refer to " «COMPONENT INSPECTION»(ref-337257-S16262482672009073100000) ".

1. CHECK ROOM LAMP TIMER SETTING CONSULT-III WORK SUPPORT Select "SET I/L D-UNLCK INTCON" of BCM (INT LAMP) work support item. Check the setting status. WORK SUPPORT Work support item Setting status SET I/L D-UNLCK INTCON On Is the setting "On"? YES: GO TO 2. NO: Change the setting to "On"
2. CHECK ROOM LAMP TIMER SIGNAL BY CONSULT-III CONSULT-III DATA MONITOR Turn ignition switch OFF. Select "ROOM LAMP REQ" of TOTAL ILLUM C/U data monitor item. While operating the door lock/door unlock, check the monitor status. MONITOR ITEM CHART Monitor item Condition Monitor status ROOM LAMP REQ Door is unlocked On Door is locked Off Is the item status normal? YES: Room lamp timer signal circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-337277-S03078795122009073100000) ".
