PHYSICAL VALUES
VOLTAGE SPECIFICATION Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 6 (P) 15 (B) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch. 0 V Keep pressing ON switch. 0.7 V Keep pressing ↓ switch. 1.3 V Keep pressing ↓ switch. 2.0 V Except for above. 3.3 V 7 (V) Ground ACC power supply Input Ignition switch ACC - Battery voltage 9 (R) Ground Illumination signal Input OFF Lighting switch is OFF. 0 V Lighting switch is ON. 12.0 V 15 (B) Ground Steering switch signal Ground - Ignition switch ON - 0 V 16 (L) 15 (B) Steering switch signal B Input Ignition switch ON Keep pressing VOL DOWN switch. 0 V Keep pressing VOL UP switch. 0.7 V Keep pressing ↑ switch. 1.3 V Except for above. 3.3 V 19 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 20 (B) Ground Ground - Ignition switch ON - 0 V 22 (B) 21 (W) Satellite radio sound signal LH Input Ignition switch ON When satellite radio mode is selected. 24 (G) 23 (R) Satellite radio sound signal RH Input Ignition switch ON When satellite radio mode is selected. 25 - Shield - - - - 26 - Shield - - - - 27 (SB) Ground Mode change signal Output Ignition switch ON Driver's Audio Stage ON 0 V Driver's Audio Stage OFF 8.5 V 28 (W) Ground Request signal (SAT-->CONT) Input Ignition switch ON When satellite radio mode is selected. 29 (B) Ground Communication signal (SAT-->CONT) Input Ignition switch ON When satellite radio mode is selected. 30 (R) Ground Communication signal (CONT-->SAT) Output Ignition switch ON When satellite radio mode is selected. 33 - FM sub Input - - - 34 - AM-FM main Input - - - 35 Ground Antenna amp. ON signal Output Ignition switch ACC - 12.0 V 36 (SB) Ground Composite image signal Output Ignition switch ON At rear camera or AUX image is displayed. 37 (V) Ground Composite image ground - Ignition switch ON - 0 V 38 (P) Ground RGB signal (B: blue) Output Ignition switch ON Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. 39 (L) Ground RGB signal (G: green) Output Ignition switch ON Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. 40 (G) Ground RGB signal (R: red) Output Ignition switch ON Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. 41 (W) Ground RGB synchronizing signal Output Ignition switch ON - 42 - Shield - - - - 43 (B) Ground RGB area (YS) signal Output Ignition switch ON At RGB image display 5.0 V At AUX image display 44 (BR) Ground Communication signal (DISP-->CONT) Input Ignition switch ON When adjusting display brightness. 45 (R) Ground Horizontal synchronizing (HP) signal Input Ignition switch ON - 46 (LG) Ground Signal ground - Ignition switch ON - 0 V 47 (O) Ground Signal VCC Output Ignition switch ACC - 9.0 V 48 (BR) - Shield - - - - 49 (Y) - Shield - - - - 50 - Shield - - - - 55 - Shield - - - - 56 (Y) Ground Communication signal (CONT-->DISP) Output Ignition switch ON When adjusting display brightness. 57 (G) Ground Vertical synchronizing (VP) signal Input Ignition switch ON - 58 (BR) Ground Inverter ground - Ignition switch ON - 0 V 59 (Y) Ground Inverter VCC Output Ignition switch ACC - 9.0 V 64 - Shield - - - - 65 (W) Ground Camera image signal Input Ignition switch ON At rear camera image display 66 (G) Ground AUX image signal Input Ignition switch ON At AUX image display 68 (W) Ground Camera-connection recognition signal - Ignition switch ON Connected to camera control unit connector. 0 V Not connected to camera control unit connector. 5.0 V 73 - Shield - - - - 74 (R) Ground AUX image signal ground - Ignition switch ON - 0 V 80 (L) 79 (P) TEL voice signal Input Ignition switch ON During voice guide output with the switch pressed. 81 - Shield - - - - 83 (BR) 82 (Y) iPod sound signal RH Input Ignition switch ON When iPod mode is selected. 85 (B) Ground Ground - Ignition switch ON - 0 V 86 (L) - CAN-H Input/Output - - - 87 (P) - CAN-L Input/Output - - - 88 (LG) - AV communication signal (H) Input/Output - - - 89 (V) - AV communication signal (L) Input/Output - - - 90 (G) - AV communication signal (H) Input/Output - - - 91 (V) (1) (R) (2) - AV communication signal (L) Input/Output - - - 95 (B) 97 (W) AUX sound signal RH Input Ignition switch ON When AUX mode is selected. 96 (R) 97 (W) AUX sound signal LH Input Ignition switch ON When AUX mode is selected. 99 (R) 98 (G) iPod sound signal LH Input Ignition switch ON When iPod mode is selected. 101 (BR) Ground Switch ground - Ignition switch ON - 0 V 103 (SB) Ground Disk eject signal Input - Pressing the eject switch. 0 V Except for above 3.3 V 104 (G) Ground Ignition signal Input Ignition switch ON - Battery voltage 105 (O) Ground Reverse signal Input Ignition switch ON R position 12.0 V Other than R position 0 V 106 (V) Ground Parking brake signal Input Ignition switch ON Parking brake ON 0 V Parking brake OFF 107 (R) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 108 (BR) 114 (Y) Sound signal rear RH Output Ignition switch ON Audio output 109 (R) 115 (G) Sound signal front RH Output Ignition switch ON Audio output 110 (V) Ground Amp. ON signal Output Ignition switch ON - 10.0 V 111 - Shield - - - - 112 (V) 118 (LG) (1) (SB) (2) Sound signal rear LH Output Ignition switch ON Audio output 113 (P) 119 (L) Sound signal front LH Output Ignition switch ON Audio output (1) With hands-free phone (2) Without hands-free phone
Scheme 147
Scheme 148
Scheme 149
Scheme 150
Scheme 151
Scheme 152
Scheme 153
Scheme 154
Scheme 155
Scheme 156
Scheme 157
Scheme 158
Scheme 159
Scheme 160
Scheme 161
Scheme 162
Scheme 163
Scheme 164
TERMINAL REFERENCE CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (B) Ground Ground - Ignition switch ON - 0 V 2 (Y) Ground Inverter VCC Input Ignition switch ACC - 9.0 V 3 (O) Ground Signal VCC Input Ignition switch ACC - 9.0 V 4 (V) Ground Composite image ground - Ignition switch ON - 0 V 5 (Y) - Shield - - - - 6 (L) Ground RGB signal (G: green) Input Ignition switch ON Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. 7 - Shield - - - - 8 (R) Ground Horizontal synchronizing (HP) signal Output Ignition switch ON - 9 (B) Ground RGB area (YS) signal Input Ignition switch ON At RGB image display 5.0 V At AUX image display 11 (Y) Ground Communication signal (CONT-->DISP) Input Ignition switch ON When adjusting display brightness. 13 (BR) Ground Inverter ground - Ignition switch ON - 0 V 14 (LG) Ground Signal ground - Ignition switch ON - 0 V 15 (SB) Ground Composite image signal Input Ignition switch ON At AUX image display 16 (BR) - Shield - - - - 17 (G) Ground RGB signal (R: red) Input Ignition switch ON Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. 18 (P) Ground RGB signal (B: blue) Input Ignition switch ON Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. 19 (W) Ground RGB synchronizing signal Input Ignition switch ON - 20 (G) Ground Vertical synchronizing (VP) signal Output Ignition switch On - 21 - Shield - - - - 22 (BR) Ground Communication signal (DISP-->CONT) Output Ignition switch ON When adjusting display brightness. 23 - Shield
Scheme 165
Scheme 166
Scheme 167
Scheme 168
Scheme 169
Scheme 170
TERMINAL REFERENCE CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (Y) 10 (G) Sound signal rear door speaker LH Output Ignition switch ON Audio output 2 (SB) 3 (V) Sound signal rear door speaker RH Output Ignition switch ON Audio output 4 (L) 5 (P) Sound signal front door speaker LH Output Ignition switch ON Audio output 6 (O) 7 (W) Sound signal front squawker LH Output Ignition switch ON Audio output 8 (LG) 13 (Y) Sound signal front door speaker RH Output Ignition switch ON Audio output 9 (G) 14 (R) Sound signal woofer and rear squawker (LH and RH) Output Ignition switch ON Audio output 11 (GR) Ground Battery power supply Input Ignition switch OFF - Battery voltage 12 (B) Ground Ground - Ignition switch ON - 0 V 15 (Y) 28 (G) Sound signal center speaker Output Ignition switch ON Audio output 17 (O) Ground Mode change signal Input Ignition switch ON Driver's Audio Stage ON 0 V Driver's Audio Stage OFF 8.5 V 18 (P) 32 (L) Sound signal front LH Input Ignition switch ON Audio output 19 (R) 20 (G) Sound signal front RH Input Ignition switch ON Audio output 21 (V) 22 (SB) Sound signal rear LH Input Ignition switch ON Audio output 23 (BR) 33 (Y) Sound signal rear RH Input Ignition switch ON Audio output 25 (L) Ground Woofer amp. ON signal Output Ignition switch ACC - 12.0 V 37 (V) 27 (LG) Sound signal front squawker RH Output Ignition switch ON Audio output 31 (GR) Ground Amp. ON signal Input Ignition switch ACC - 12.0 V
Scheme 171
Scheme 172
Scheme 173
Scheme 174
Scheme 175
Scheme 176
Scheme 177
Scheme 178
TERMINAL REFERENCE CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (R) 13 (G) iPod sound signal LH Output Ignition switch ON When iPod mode is selected. 2 (BR) 14 (Y) iPod sound signal RH Output Ignition switch ON When iPod mode is selected. 3 (O) Ground ACC power supply Input Ignition switch ACC - Battery voltage 4 (V) - AV communication signal (L) Input/Output - - - 5 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 8 (W) Ground iPod battery charge Output Ignition switch ON Connected to iPod® 12.0 V 9 (Y) Ground Communication signal (iPod adapter-->iPod®) Output Ignition switch ON The wave pattern is displayed just after iPod connection. NOTE: After the wave pattern display, the value continues Approx 3.3 V 10 (BR) Ground Communication signal (iPod®-->iPod adapter) Input Ignition switch ON Connected to iPod® 11 (L) Ground ACCESSORY-IDENTIFY - Ignition switch ON Connected to iPod® 0 V 12 (R) 23 (W) iPod sound signal RH Input Ignition switch ON When iPod mode is selected. 15 - Shield - - - - 16 (LG) - AV communication signal (H) Input/Output - - - 17 (B) Ground Ground - Ignition switch ON - 0 V 19 - Shield - - - - 21 (SB) Ground iPod connection recognition signal Input Ignition switch ON Not connected to iPod® 4.0 V Connected to iPod® 0 V 22 (W) Ground ACCESSORY-DETECT - Ignition switch ON Connected to iPod® 0 V 24 (B) 23 (W) iPod sound signal LH Input Ignition switch ON When iPod mode is selected
Scheme 179
Scheme 180
Scheme 181
TERMINAL REFERENCE CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 5 - Shield - - - - 6 (W) Ground Camera image signal Input Ignition switch ON At rear camera image display 7 (B) Ground Camera ground - Ignition switch ON - 0 V 8 (R) Ground Camera power supply Output Ignition switch ON R position 6.0 V Other than R position 0 V 11 - Shield - - - - 12 (W) Ground Camera image signal Output Ignition switch ON At rear camera image display 14 (R) Ground Camera connection recognition signal - Ignition switch ON Connected to camera control unit connector 0 V Not connected to camera control unit connector 5.0 V 17 (P) - AV communication signal (L) Input/Output - - - 18 (L) - AV communication signal (H) Input/Output - - - 19 (B) - AV communication signal (L) Input/Output - - - 20 (W) - AV communication signal (H) Input/Output - - - 22 (O) Ground Reverse signal Input Ignition switch ON R position 12.0 V Other than R position 0 V 26 (G) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 30 (B) Ground ACC power supply Input Ignition switch ACC - Battery voltage 31 (B) Ground Ground - Ignition switch ON - 0 V 32 (SB) Ground Battery power supply Input Ignition switch OFF - Battery voltage
Scheme 182
TERMINAL REFERENCE CHART Terminal Description Condition Reference value (Approx.) + - Signal name Input/Output 2 (R) 1 (G) Satellite radio sound signal LH Output Ignition switch ON When satellite radio mode is selected. 4 (B) 3 (W) Satellite radio sound signal RH Output Ignition switch ON When satellite radio mode is selected. 5 - Shield - - - - 6 - Shield - - - - 8 (W) Ground Request signal (SAT-->CONT) Output Ignition switch ON When satellite radio mode is selected. 9 (B) Ground Communication signal (SAT-->CONT) Output Ignition switch ON When satellite radio mode is selected. 10 (R) Ground Communication signal (CONT-->SAT) Input Ignition switch ON When satellite radio mode is selected. 12 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 16 (V) Ground ACC power supply Input Ignition switch ACC - Battery voltage 33 - Satellite antenna Input
Scheme 183
TERMINAL REFERENCE CHART Terminal (Wire color) Description Condition Reference value (Approx.) + - Signal name Input/Output 1 (Y) Ground Battery power supply Input Ignition switch OFF - Battery voltage 2 (LG) Ground ACC power supply Input Ignition switch ACC - Battery voltage 3 (W) Ground Ignition signal Input Ignition switch ON - Battery voltage 4 (B) Ground Ground - Ignition switch ON - 0 V 7 (L) 8 Microphone signal Input Ignition switch ON Give a voice 8 Ground Microphone ground - Ignition switch ON - 0 V 9 (L) 10 (P) TEL voice signal Output Ignition switch ON During voice guide output with the switch pressed. 20 (B) Ground Control signal - Ignition switch ON - 0 V 23 (B) Ground Control signal - Ignition switch ON - 0 V 24 (B) Ground Control signal - Ignition switch ON - 0 V 28 (P) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) NOTE: The maximum voltage varies depending on the specification (destination unit). 29 (P) 8 Microphone VCC Output Ignition switch ON - 5.0 V 33 - TEL antenna Input - - - 34 - Shield - - - - 35 (L) - AV communication signal (H) Input/Output - - - 36 (P) - AV communication signal (L) Input/Output
