Car Wiring Diagrams for Cruise control circuit for Infiniti FX35 I facelift (2006-2008)

101 104 99 82 94 86 108 BRAKE MOTRLY ASCD SW GND-A CAN-H CAN-L BNCSW 19 9 11 1 RX TX CAN-L CAN-H 4.5L 3.5L ASCD BRAKE SWITCH (ON BRAKE PEDAL BRACKET) ASCD STEERING SWITCH AVCC GND-A BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM PNK WIRE CRUISE IND (GREEN) ELECTRIC THROTTLE CONTROL ACTUATOR (TOP LEFT SIDE OF ENGINE) ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT END OF DASH) FUSE 12 FUSE 14 FUSE 19 FUSE 20 FUSE 87 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) GRN WIRE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE MAIN NCA WIRE ORG/ WIRE PNK WIRE PNK/BLU WIRE PPL PPL PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RESUME/ ACCEL SENSOR 1 SENSOR 2 SENSOR 2 ACCELERATOR PEDAL POSITION SENSOR (ON ACCELERATOR PEDAL BRACKET) SET IND SET/ COAST STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) THROTTLE CONTROL MOTOR THROTTLE CONTROL MOTOR RELAY UNIFIED METER CONTROL UNIT UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER CONSOLE) WHT WIRE YEL WIRE YEL/RED WIRE
