Infiniti FX35 I facelift (2006-2008) open close half switch switch latch switch Wiring diagram
This page shows the only wiring diagram for the component.open close half switch switch latch switch, which is found in the car Infiniti FX35 I facelift (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open close half switch switch latch switch (1 of 1)
BACK DOOR CLOSURE CONTROL UNIT (LOWER LEFT SIDE OF BACK DOOR)
BACK DOOR CLOSURE MOTOR (LOWER CENTER OF BACK DOOR)
BACK DOOR OPEN OUTPUT
BACK DOOR OPENER SWITCH
BLK WIRE
BLU WIRE
DOOR LOCKS SYSTEM
DOOR SWITCH
FUSE 18
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
INTELLIGENT KEY UNIT (BEHIND LEFT END OF DASH)
LT GRN WIRE
OFF
ON OFF OFF
ON ON CLOSED
OPEN CLOSE HALF SWITCH SWITCH LATCH SWITCH
OPEN/ CLOSE MOTOR
ORG/ WIRE
PNK BACK DOOR OPEN SWITCH WIRE
PNK WIRE
PPL
RED WIRE
YEL WIRE
Go to component -> Power liftgate circuit, with intelligent key unit -> OPEN CLOSE HALF SWITCH SWITCH LATCH SWITCH
