Infiniti FX35 I facelift (2006-2008) memory switch-2 memory switch-1 Wiring diagram
This page shows the only wiring diagram for the component.memory switch-2 memory switch-1, which is found in the car Infiniti FX35 I facelift (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory switch-2 memory switch-1 (1 of 1)
11 38 39 40 ACC SW IGN SW CAN-H CAN-L
55 52 49 42 BAT (F/L) GND (POWER) GND (SIG) (FUSE) BATT
AUTOMATIC DRIVE POSITIONER CONTROL UNIT (LOWER CENTER CONSOLE)
BACKWARD FORWARD
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BWD FWD BWD
CAN L
CAN-H
CIRCUIT BREAKER (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 22
FUSE 6 (BEHIND LEFT KICK PANEL)
FUSE 9
FUSE BLOCK (J/B)
GND POWER
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN
HOT IN ON OR ACC
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
MEMORY INDICATOR 1
MEMORY INDICATOR 2
MEMORY SWITCH-2 MEMORY SWITCH-1
MIRROR MOTOR (RH COM) MIRROR MTR (LH VERT) MIRROR MTR (LH HORIZ)
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SEAT MEMORY SWITCH
SET SWITCH
TELESCOPIC MOTOR (BACK)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Memory systems circuit (1 of 4) -> MEMORY SWITCH-2 MEMORY SWITCH-1
