Glasses, Window System & Mirrors: Removal & Installation Infiniti FX35 I рестайлинг

Windows 7 illustrations ~1128 words

INSTALLATION

  1. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
  3. The molding must be installed securely so that it is in position and leaves no gap.
  4. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the windshield in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidities. The curing time will increase under lower temperature and lower humidity.

Repairing Water Leaks for Windshield

Leaks can be repaired without removing and reinstalling glass.

If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.

This can be done by applying water to the windshield area while pushing glass outward.

To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.

Scheme 60

Scheme 60: Removal and Installation
Scheme 60: Removal and Installation

Scheme 61

Scheme 61: REMOVAL
Scheme 61: REMOVAL
  1. Remove the back door finisher. Refer to " «BACK DOOR TRIM»(ref-282584-S10773203282008040500000) ".
  2. Remove the rear wiper arm. Refer to " «REMOVAL AND INSTALLATION OF REAR WIPER AND WASHER SWITCH»(ref-282617-S07573026022008040500000) ".
  3. Remove the connectors and grounds for the rear window defogger. After removing molding, remove glass using cutting knife or power cutting tool and an inflatable pump bag. If a back door window glass is to be reused, mark the body and the glass with mating marks. WARNING: When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands. CAUTION: Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks.
  4. Remove the back door window glass, using suction liter.
  1. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
  3. The molding must be installed securely so that it is in position and leaves no gap.
  4. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the back door window glass in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidity. The curing time will increase under lower temperature and lower humidity.

Scheme 62

Scheme 62: Component Parts and Harness Connector Location
Scheme 62: Component Parts and Harness Connector Location

REMOVAL

  1. Remove the roof rear garnish. Refer to " «REMOVAL AND INSTALLATION»(ref-282584-S02893453502008040500000) ".
  2. Remove the luggage side finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-282584-S02893453502008040500000) ".
  3. Remove the rear pillar upper garnish. Refer to " «REMOVAL AND INSTALLATION»(ref-282584-S02893453502008040500000) ".
  4. Apply a protective tape around the side window glass to protect the painted surface from damage. Remove side window glass using piano wire or power cutting tool and an inflatable pump bag. WARNING: When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent glass splinters from entering your eyes or cutting your hands. CAUTION: Be careful not to scratch the glass when removing. Do not set or stand the glass on its edge. Small chips may develop into cracks.
  1. Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
  2. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger room air pressure when a door is closed.
  3. The molding must be installed securely so that it is in position and leaves no gap.
  4. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNINGKeep heat and open flames away as primers and adhesive are flammable. The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid contact with the skin and eyes. Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled. If affected by vapor inhalation, immediately move to an area with fresh air. Driving the vehicle before the urethane adhesive has completely cured may affect the performance of the side window in case of an accident.
CAUTIONDo not use an adhesive which is past its usable term. Shelf life of this product is limited to six months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box. Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. Do not leave primers or adhesive cartridge unattended with their caps open or off. The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely cured. Curing time varies depending on temperature and humidities. The curing time will increase under lower temperature and lower humidity.

Install in the reverse order of removal.

Scheme 63

Scheme 63
Scheme 63
  1. Remove the front door finisher. Refer to " «DOOR FINISHER»(ref-282584-S08742957642008040500000) ".
  2. Remove speaker unit. Refer to " «REMOVAL AND INSTALLATION FOR FRONT DOOR SPEAKER»(ref-282618-S22426935652008040500000) ".
  3. Operate the power window main switch to raise/lower the door window until the glass mounting bolts can be seen.
  4. Remove the glass mounting bolts.
  5. Remove the module stop bolts.
  6. Raise up the door glass and hold with a suction lifter.
  7. Remove the mounting bolts, and remove the module assembly.
  8. Disconnect the harness connector for the module assembly, and unclip the harness from the back.

Install in the reverse order of removal.

  1. Remove the rear door finisher. Refer to " «DOOR FINISHER»(ref-282584-S08742957642008040500000) ".
  2. Remove the rear door outside molding. Refer to " «DOOR OUTSIDE MOLDING»(ref-282584-S08423404772008040500000) ".
  3. Remove the sealing screen.
  4. Lower the door glass.
  5. Remove the corner piece screws and bolt.
  6. Remove the corner piece assembly.
  7. Operate the power window switch to raise/lower the door window until the glass mounting bolts can be seen.
  8. Remove the glass mounting bolts, and remove the glass from the inside of the panel.

Install in the reverse order of removal.

Scheme 64

Scheme 64: Removal
Scheme 64: Removal

Scheme 65

Scheme 65
Scheme 65
  1. Remove the rear door finisher. Refer to " «DOOR FINISHER»(ref-282584-S08742957642008040500000) ".
  2. Remove the rear door outside molding. Refer to " «DOOR OUTSIDE MOLDING»(ref-282584-S08423404772008040500000) ".
  3. Remove the sealing screen.
  4. Lower the door glass.
  5. Remove the corner piece screws and bolt.
  6. Remove the corner piece assembly.
  7. Operate the power window switch to raise/lower the door window until the glass mounting bolts can be seen.
  8. Remove the glass mounting bolts.
  9. Raise up the door glass and hold with a suction lifter.
  10. Remove the power window motor mounting bolts and nuts, and remove the regulator from the panel.
  11. Disconnect the connector for the regulator assembly.

Install in the reverse order of removal.

  1. Remove inside mirror cover.
  2. Remove inside mirror finisher.
  3. Remove TORX bolt (T20) of the mirror base.
  4. Slide the mirror base upward to remove.
  5. Disconnect the connector.

Install in the reverse order of removal.

  1. Remove the front door finisher. Refer to " «DOOR FINISHER»(ref-282584-S08742957642008040500000) ".
  2. Remove the corner cover inner.
  3. Remove the door mirror harness connector.
  4. Remove the door mirror mounting nuts, and remove the door mirror assembly.

Install in the reverse order of removal.

Scheme 66

Scheme 66: DISASSEMBLY
Scheme 66: DISASSEMBLY
  1. Place the mirror body with mirror glass facing upward.
  2. Put strip of protection tape on mirror body.
  3. As shown in the figure insert a small flat-bladed screwdriver into the recess between mirror base (mirror holder) and mirror holder bracket and push up pawls to remove mirror holder lower half side. NOTE: When pushing up pawls do not attempt to use 1 recess only, be sure to push up with both recesses. Insert screwdriver into recesses, and push up while rotating (twist) to make work easier.
  4. Remove terminals of mirror heater attachment.
  5. Lightly lift up lower side of mirror surface, and detach pawls of upper side from bracket as if pulling it out. Remove mirror surface from mirror body. NOTE: Be certain not to allow grease on sealing agent in center of mirror body assembly (actuator) or back side of mirror surface (mirror holder).
