FLUID LEAKAGE

Check transfer surrounding area (oil seal, drain plug, and filler plug etc.) for fluid leakage.

Scheme 51

Scheme 51: FLUID LEVEL
  1. Remove filler plug (1) and gasket. Then check that fluid is filled up from mounting hole for the filler plug. CAUTION: Never start engine while checking fluid level.
  2. Before installing filler plug, set a new gasket. Install filler plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-368804-S42890701032010081300000) ". CAUTION: Never reuse gasket.

Scheme 52

Scheme 52: Draining
  1. Run the vehicle to warm up the transfer unit sufficiently.
  2. Stop the engine, and remove the drain plug (1) to drain the transfer fluid. CAUTION: When draining fluid, protect exhaust tube flange with cover.
  3. Apply sealant to drain plug. Install drain plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-368804-S42890701032010081300000) ". Use Genuine Silicone RTV or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-368779-S01206784092010081300000) ". CAUTION: Remove old sealant adhering to mounting surfaces. Also remove any moisture, oil, or foreign material adhering to application and mounting surfaces.

Refilling

  1. Remove filler plug (1) and gasket. Then fill fluid up to mounting hole for the filler plug. Fluid and viscosity : Refer to " «FLUIDS AND LUBRICANTS»(ref-368818-S36739250962010081300000) ". Fluid capacity : Refer to " «GENERAL SPECIFICATIONS»(ref-368804-S27645971582010081300000) ". CAUTION: Carefully fill the fluid. (Fill up for approximately 3 minutes.)
  2. Leave the vehicle for 3 minutes, and check the fluid level again.
  3. Set a new gasket onto filler plug and install it on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-368804-S42890701032010081300000) ". CAUTION: Never reuse gasket.

Scheme 53

Scheme 53: Exploded View

Scheme 54

Scheme 54: REMOVAL
  1. Remove the glove box assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-368793-S37538083022010081300000) ".
  2. Disconnect AWD control unit harness connector.
  3. Remove AWD control unit (1) mounting nuts.
  4. Remove AWD control unit.
