Contents Wiring diagrams Section: Procedures All sections

Maintenance: Other Infiniti EX35 I

Procedures 21 illustrations ~1610 words

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOL SPECIFICATION Tool number (Kent-Moore No.) Tool name Description KV10115801 (J38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)

Commercial Service Tool

COMMERCIAL SERVICE TOOL SPECIFICATION Tool name (Kent-Moore No.) Description Power tool (-) Loosening nuts and bolts Spark plug wrench (-) Removing and installing spark plug 14 mm (0.55 in)

Scheme 28

Scheme 28: Commercial Service Tool

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their INFINITI dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

ItemReference
TiresCheck the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear.TIRE AIR PRESSURE
Wheel nutsWhen checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary.
Tire rotationTires should be rotated every 12,000 km (7,500 miles).TIRE ROTATION
Tire Pressure Monitoring System (TPMS) transmitter componentsReplace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age.TRANSMITTER
Wheel alignment and balanceIf the vehicle should pull to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed.WHEEL ALIGNMENT (2WD) WHEEL ALIGNMENT (AWD) WHEEL ALIGNMENT WHEELS (BONDING WEIGHT TYPE)
WindshieldClean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary.
Windshield wiper bladesCheck for cracks or wear if they do not wipe properly.
Doors and engine hoodCheck that all doors and the engine hood operate smoothy as well as the back door, trunk lid and glass hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently.BODY MAINTENANCE
LampsMake sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis.

GENERAL MAINTENANCE EXPLANATION CHART - OUTSIDE VEHICLE

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

ItemReference
Warning lamps and chimesMake sure that all warning lamps and chimes are operating properly.
Windshield wiper and washerCheck that the wipers and washer operate properly and that the wipers do not streak.
Windshield defrosterCheck that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioner.
Steering wheelCheck that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in)
SeatsCheck seat position controls such as seat adjusters, seatback recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restrains move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seatbacks.
Seat beltsCheck that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly, and are installed securely. Check the belt webbing for cuts, fraying, wear or damage.SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS
Accelerator pedalCheck the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal.
BrakesCheck that the brake does not pull the vehicle to one side when applied.
Brake pedal and boosterCheck the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep the floor mats away from the pedal.BRAKE PEDAL BRAKE BOOSTER
Parking brakeCheck that the pedal has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied.PARKING BRAKE SYSTEM
Automatic transmission "Park" mechanismCheck that the lock release button on the selector lever operates properly and smoothly. On a fairly steep hill check that the vehicle is held securely with the selector lever in the P (Park) position without applying any brakes.

GENERAL MAINTENANCE EXPLANATION CHART - INSIDE VEHICLE

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

ItemReference
Windshield washer fluidCheck that there is adequate fluid in the tank.
Engine coolant levelCheck the coolant level when the engine is cold.ENGINE COOLANT
Radiator and hosesCheck the front of the radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the hoses have no cracks, deformation, deterioration or loose connections.
Brake fluid levelMake sure that the brake and clutch fluid level is between the "MAX" and "MIN" lines on the reservoir.BRAKE FLUID LEVEL AND LEAKS
BatteryCheck the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level.BATTERY
Engine drive beltMake sure that no belt is frayed, worn, cracked or oily.DRIVE BELT
Engine oil levelCheck the level on the oil level gauge after parking the vehicle on a level spot and turning off the engine.ENGINE OIL
Power steering fluid level and linesCheck the level on the dipstick with the engine off. Check the lines for improper attachment, leaks, cracks, etc.POWER STEERING FLUID AND LINES
Exhaust systemMake sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it.EXHAUST SYSTEM
UnderbodyThe underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate.
Fluid leaksCheck under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately.

GENERAL MAINTENANCE EXPLANATION CHART - UNDER HOOD AND VEHICLE

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals.

Schedule 1Follow Periodic Maintenance Schedule 1 if the driving habits frequently include one or more of the following driving conditions: Repeated short trips of less than 5 miles (8 km). Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing. Operating in hot weather in stop-and-go "rush hour" traffic. Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use. Driving in dusty conditions. Driving on rough, muddy, or salt spread roads. Towing a trailer, using a camper or a car-top carrier.Emission Control System MaintenanceEMISSION CONTROL SYSTEM
Chassis and Body Maintenance
Schedule 2Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in Schedule 1 apply to the driving habits.Emission Control System MaintenanceEMISSION CONTROL SYSTEM
Chassis and Body Maintenance

PERIODIC MAINTENANCE INTRODUCTION CHART

EMISSION CONTROL SYSTEM

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATIONMAINTENANCE INTERVALReference Information - Content Title
Perform at number of miles, kilometers or months, whichever comes first.Miles x 1,000 (km x 1,000) Months3.75 (6) 37.50 (12) 611.25 (18) 915 (24) 1218.75 (30) 1522.5 (36) 1826.25 (42) 2130 (48) 24
Drive belt(1)DRIVE BELT
Air cleaner filter(2)[R]AIR CLEANER FILTER
EVAP vapor linesI (6)EVAP VAPOR LINES
Fuel linesI (6)FUEL LINES
Fuel filter(3)
Engine coolant(4)ENGINE COOLANT
Engine oilRRRRRRRRENGINE OIL
Engine oil filter - Use genuine NISSAN engine oil filter or equivalent.RRRRRRRROIL FILTER
Spark plugs (Iridium-tipped type)Replace every 105,000 miles (169,000 km).SPARK PLUG
Intake & exhaust valve clearance (6)(5)CAMSHAFT VALVE CLEARANCE
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
(1)After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.
(2)If operating mainly in dusty conditions, more frequent maintenance may be required.
(3)Maintenance-free item. For service procedures, refer to FUEL SYSTEM .
(4)After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5)Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.
(6)Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

EMISSION CONTROL SYSTEM PERIODIC MAINTENANCE CHART - SCHEDULE 1

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATIONMAINTENANCE INTERVALReference Information - Content Title
Perform at number of miles, kilometers or months, whichever comes first.Miles x 1,000 (km x 1,000) Months33.75 (54) 2737.5 (60) 3041.25 (66) 3345 (72) 3648.75 (78) 3952.5 (84) 4256.25 (90) 4560 (96) 48
Drive belt(1)I (6)DRIVE BELT
Air cleaner filter(2)[R]AIR CLEANER FILTER
EVAP vapor linesI (6)EVAP VAPOR LINES
Fuel linesI (6)FUEL LINES
Fuel filter(3)
Engine coolant(4)R (6)ENGINE COOLANT
Engine oilRRRRRRRRENGINE OIL
Engine oil filter - Use genuine NISSAN engine oil filter or equivalent.RRRRRRRROIL FILTER
Spark plugs (Iridium-tipped type)Replace every 105,000 miles (169,000 km).SPARK PLUG
Intake & exhaust valve clearance (6)(5)CAMSHAFT VALVE CLEARANCE
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
(1)After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.
(2)If operating mainly in dusty conditions, more frequent maintenance may be required.
(3)Maintenance-free item. For service procedures, refer to FUEL SYSTEM .
(4)After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5)Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.
(6)Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

EMISSION CONTROL SYSTEM PERIODIC MAINTENANCE CHART - SCHEDULE 1

CHASSIS AND BODY

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATIONMAINTENANCE INTERVALReference Information - Content Title
Perform at number of miles, kilometers or months, whichever comes first.Miles x 1,000 (km x 1,000) Months3.75 (6) 37.50 (12) 611.25 (18) 915 (24) 1218.75 (30) 1522.5 (36) 1826.25 (42) 2130 (48) 24
Brake lines & cablesIIBRAKE LINES AND CABLES
Brake pads & rotorsIIIIDISC BRAKE
Automatic transmission fluid(1)
Transfer fluid & differential gear oil(2)IITRANSFER FLUID FRONT DIFFERENTIAL GEAR OIL: F160A FRONT DIFFERENTIAL GEAR OIL: F160A : REFILLING
Steering gear & linkage, axle & suspension partsIIIISTEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS
Tire rotation(3)TIRE ROTATION TIRE ROTATION
Propeller shaft and drive shaft boots (AWD models)IIIIFRONT PROPELLER SHAFT: 2S56A REAR PROPELLER SHAFT: 3S80A-R : INSPECTION REAR PROPELLER SHAFT: 3S80A-R : INSPECTION DRIVE SHAFT
Exhaust systemIIIIEXHAUST SYSTEM
In-cabin microfilterRRIN-CABIN MICROFILTER
(1) Automatic transmission fluid is maintenance-free. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30,000 miles (48,000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "General maintenance" heading earlier in this information.
(1)Automatic transmission fluid is maintenance-free.
(2)If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30,000 miles (48,000 km) or 24 months.
(3)Refer to " TIRE ROTATION " under the "General maintenance" heading earlier in this information.

CHASSIS AND BODY PERIODIC MAINTENANCE CHART - SCHEDULE 1

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATIONMAINTENANCE INTERVALReference Information - Content Title
Perform at number of miles, kilometers or months, whichever comes first.Miles x 1,000 (km x 1,000) Months33.75 (54) 2737.5 (60) 3041.25 (66) 3345 (72) 3648.75 (78) 3952.5 (84) 4256.25 (90) 4560 (96) 48
Brake lines & cablesIIBRAKE LINES AND CABLES
Brake pads & rotorsIIIIDISC BRAKE
Automatic transmission fluid(1)
Transfer fluid & differential gear oil(2)IITRANSFER FLUID FRONT DIFFERENTIAL GEAR OIL: F160A FRONT DIFFERENTIAL GEAR OIL: F160A : REFILLING
Steering gear & linkage, axle & suspension partsIIIISTEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS
Tire rotation(3)TIRE ROTATION TIRE ROTATION
Propeller shaft and drive shaft boots (AWD models)IIIIFRONT PROPELLER SHAFT: 2S56A REAR PROPELLER SHAFT: 3S80A-R : INSPECTION REAR PROPELLER SHAFT: 3S80A-R : INSPECTION DRIVE SHAFT
Exhaust systemIIIIEXHAUST SYSTEM
In-cabin microfilterRRIN-CABIN MICROFILTER
(1) Automatic transmission fluid is maintenance-free. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30,000 miles (48,000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "General maintenance" heading earlier in this information.
(1)Automatic transmission fluid is maintenance-free.
(2)If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30,000 miles (48,000 km) or 24 months.
(3)Refer to " TIRE ROTATION " under the "General maintenance" heading earlier in this information.

CHASSIS AND BODY PERIODIC MAINTENANCE CHART - SCHEDULE 1

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATIONMAINTENANCE INTERVALReference Information - Content Title
Perform at number of miles, kilometers or months, whichever comes first.Miles x 1,000 (km x 1,000) Months7.5 (12) 615 (24) 1222.5 (36) 1830 (48) 2437.5 (60) 3045 (72) 3652.5 (84) 4260 (96) 48
Drive belt(1)I (5)DRIVE BELT
Air cleaner filter[R][R]AIR CLEANER FILTER
EVAP vapor linesI (5)I (5)EVAP VAPOR LINES
Fuel linesI (5)I (5)FUEL LINES
Fuel filter(2)
Engine coolant(3)R (5)ENGINE COOLANT
Engine oilRRRRRRRRENGINE OIL
Engine oil filter - Use genuine NISSAN engine oil filter or equivalent.RRRRRRRROIL FILTER
Spark plugs (Iridium-tipped type)Replace every 105,000 miles (169,000 km).SPARK PLUG
Intake & exhaust valve clearance (5)(4)CAMSHAFT VALVE CLEARANCE
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) Maintenance-free item. For service procedures, refer to FUEL SYSTEM . (3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months. (4) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (5) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
(1)After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.
(2)Maintenance-free item. For service procedures, refer to FUEL SYSTEM .
(3)After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4)Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.
(5)Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

EMISSION CONTROL SYSTEM PERIODIC MAINTENANCE CHART - SCHEDULE 2

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATIONMAINTENANCE INTERVALReference Information - Content Title
Perform at number of miles, kilometers or months, whichever comes first.Miles x 1,000 (km x 1,000) Months7.5 (12) 615 (24) 1222.5 (36) 1830 (48) 2437.5 (60) 3045 (72) 3652.5 (84) 4260 (96) 48
Brake lines & cablesIIIIBRAKE LINES AND CABLES
Brake pads & rotorsIIIIDISC BRAKE
Automatic transmission fluid(1)IIII
Transfer fluid & differential gear oilIIIITRANSFER FLUID FRONT DIFFERENTIAL GEAR OIL: F160A FRONT DIFFERENTIAL GEAR OIL: F160A : REFILLING
Steering gear & linkage, axle & suspension partsIISTEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS
Tire rotation(2)TIRE ROTATION TIRE ROTATION
Propeller shaft and drive shaft boots (AWD models)IIIIFRONT PROPELLER SHAFT: 2S56A REAR PROPELLER SHAFT: 3S80A-R : INSPECTION REAR PROPELLER SHAFT: 3S80A-R : INSPECTION DRIVE SHAFT
Exhaust systemIIEXHAUST SYSTEM
In-cabin microfilterRRRRIN-CABIN MICROFILTER
(1) Automatic transmission fluid maintenance-free. (2) Refer to " TIRE ROTATION " under the "General maintenance" heading earlier in this information.
(1)Automatic transmission fluid maintenance-free.
(2)Refer to " TIRE ROTATION " under the "General maintenance" heading earlier in this information.

CHASSIS AND BODY PERIODIC MAINTENANCE CHART - SCHEDULE 2

Engine Oil Recommendation

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.

Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Scheme 29

Scheme 29: Engine Oil Recommendation

Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a high-quality, year-round, anti-freeze coolant solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system additives are not necessary.

CAUTIONWhen adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant or equivalent with the proper mixture ratio of 50% anti-freeze and 50% demineralized water/distilled water. Other types of coolant solutions may damage your cooling system.

Scheme 30

Scheme 30

Scheme 31

Scheme 31: DRIVE BELT : Exploded View

DRIVE BELT : Checking

WARNINGBe sure to perform this step when engine is stopped.
  1. Check that the indicator (C) (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A). NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (B) in the figure.
  2. Visually check entire drive belt for wear, damage or cracks.
  3. If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.

RUNOUT MEASURING POINT

Propeller shaft runout measuring point (Point "↑").

Standard

A : 381.5 mm (15.02 in)

Scheme 32

Scheme 32: RUNOUT MEASURING POINT

Propeller shaft runout measuring point (Point "↑").

Scheme 33

Scheme 33: RUNOUT MEASURING POINT

Standard

A : 192 mm (7.56 in)

B : 172 mm (6.77 in)

C : 172 mm (6.77 in)

Propeller shaft runout measuring point (Point "↑").

Scheme 34

Scheme 34: RUNOUT MEASURING POINT

Standard

A : 162 mm (6.38 in)

B : 245 mm (9.65 in)

C : 185 mm (7.28 in)

OIL LEAKAGE

Make sure that oil is not leaking from final drive assembly or around it.

Scheme 35

Scheme 35: OIL LEVEL
  1. Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
  2. Set a gasket on filler plug (1) and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-368823-S12905013132010081300000) ". CAUTION: Never reuse gasket.

Scheme 36

Scheme 36: FRONT DIFFERENTIAL GEAR OIL: F160A : Draining
  1. Stop engine.
  2. Remove drain plug (1) and drain gear oil.
  3. Set a gasket on drain plug (1) and install it to final drive assembly and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-368823-S12905013132010081300000) ". CAUTION: Never reuse gasket.
  1. Make sure that oil is not leaking from final drive assembly or around it.

Scheme 37

Scheme 37: OIL LEVEL
  1. Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
  2. Set a gasket on filler plug (1) and install it on final drive assembly. Refer to " «2WD : EXPLODED VIEW»(ref-368830-S04531574032010081300000) " (2WD), " «AWD : EXPLODED VIEW»(ref-368830-S21489498022010081300000) " (AWD). CAUTION: Never reuse gasket.

Scheme 38

Scheme 38: REAR DIFFERENTIAL GEAR OIL: R200 : Draining
  1. Stop engine.
  2. Remove drain plug (1) and drain gear oil.
  3. Set a gasket on drain plug (1) and install it to final drive assembly and tighten to the specified torque. Refer to " «2WD : EXPLODED VIEW»(ref-368830-S04531574032010081300000) " (2WD), " «AWD : EXPLODED VIEW»(ref-368830-S21489498022010081300000) " (AWD). CAUTION: Never reuse gasket.

BALANCING WHEELS (BONDING WEIGHT TYPE)

Preparation Before Adjustment

Using releasing agent, remove double-faced adhesive tape from the road wheel.

CAUTIONBe careful not to scratch the road wheel during removal. After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road wheel.

Wheel Balance Adjustment

If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select and adjust a drive-in weight mode suitable for road wheels.

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 41

Scheme 41
  1. Set road wheel on tire balance machine using the center hole as a guide. Start the tire balance machine.
  2. When inner and outer unbalance values are shown on the tire balance machine indicator, multiply outer unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install to the designated outer position of, or at the designated angle in relation to the road wheel. CAUTION: Do not install the inner balance weight before installing the outer balance weight. Before installing the balance weight, be sure to clean the mating surface of the road wheel. Indicated unbalance value x 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz.) x 5/3 = 38.33 g (1.35 oz.) => 37.5 g (1.32 oz.) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 36.2 => 35 g (1.23 oz.) 36.3 => 37.5 g (1.32 oz.) Installed balance weight in the position. When installing balance weight (1) to road wheels, set it into the grooved area (A) on the inner wall of the road wheel as shown in the figure so that the balance weight center (B) is aligned with the tire balance machine indication position (angle) (C). CAUTION: Always use genuine NISSAN adhesion balance weights. Balance weights are non-reusable; always replace with new ones. Do not install more than three sheets of balance weight. If calculated balance weight value exceeds 50 g (1.76 oz.), install two balance weight sheets in line with each other as shown in the figure. CAUTION: Do not install one balance weight sheet on top of another.
  3. Start the tire balance machine again.
  4. Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position (angle). CAUTION: Do not install more than two balance weight.
  5. Start the tire balance machine. Make sure that inner and outer residual unbalance values are 5 g (0.17 oz.) each or below.
  6. If either residual unbalance value exceeds 5 g (0.17 oz.), repeat installation procedures. Limit Dynamic (At flange): Refer to " «ROAD WHEEL : ROAD WHEEL»(ref-368818-S07107589972010081300000) ". Static (At flange): Refer to " «ROAD WHEEL: ROAD WHEEL»(ref-368818-S07107589972010081300000) ".

Scheme 42

Scheme 42: TIRE ROTATION
  1. Follow the maintenance schedule for tire rotation service intervals. Refer to " «EXPLANATION OF GENERAL MAINTENANCE»(ref-368818-S32776118462010081300000) ".
  2. When installing the wheel, tighten wheel nuts to the specified torque. CAUTION: Do not include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria for preventing strain of disc rotor. Use NISSAN genuine wheel nuts for aluminum wheels. Wheel nuts tightening torque : Refer to " «ROAD WHEEL : ROAD WHEEL»(ref-368818-S07107589972010081300000) ".
  3. Perform the ID registration, after tire rotation. Refer to " «ID REGISTRATION PROCEDURE : SPECIAL REPAIR REQUIREMENT»(ref-368812-S09371205912010081300000) ".

Scheme 43

Scheme 43: BRAKE FLUID LEVEL AND LEAKS : Inspection
  1. If fluid level is extremely low, check brake system for leaks.

Scheme 44

Scheme 44: BRAKE LINES AND CABLES : Inspection
  1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.

Scheme 45

Scheme 45: BRAKE FLUID : Changing
  1. Drain brake fluid from each bleed valve.
  2. Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «BLEEDING BRAKE SYSTEM»(ref-368798-S06783744382010081300000) ". Refill with recommended Genuine NISSAN Super Heavy Duty Brake Fluid or equivalent DOT 3 (US FMVSS No. 116). Refer to " «FLUIDS AND LUBRICANTS»(ref-368818-S36739250962010081300000) ". Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas.

DISC ROTOR

Check condition, wear, and damage.

Scheme 46

Scheme 46: CALIPER
  1. Check for leakage.

Scheme 47

Scheme 47: BRAKE PAD
  1. Check for wear or damage.

DISC BRAKE : Front Disc Brake

Unit: mm (in)
ItemLimit
Brake padWear thickness2.0 (0.079)
Disc rotorWear thickness26.0 (1.024)
Thickness variation (measured at 8 positions)0.015 (0.0006)
Runout (with it attached to the vehicle)0.035 (0.0014)

FRONT DISC BRAKE SPECIFICATION

DISC BRAKE : Rear Disc Brake

Unit: mm (in)
ItemLimit
Brake padWear thickness2.0 (0.079)
Disc rotorWear thickness14.0 (0.551)
Thickness variation (measured at 8 positions)0.015 (0.0006)
Runout (with it attached to the vehicle)0.055 (0.0022)

REAR DISC BRAKE SPECIFICATION

Scheme 48

Scheme 48: STEERING GEAR
  1. Check gear housing and boots for looseness, damage and grease leakage.
  2. Check connection with steering column for looseness.

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

DRIVE BELT

Tension of drive beltBelt tension is not necessary, as it is automatically adjusted by drive belt auto-tensioner.

DRIVE BELT SPECIFICATION

SPARK PLUG

Unit: mm (in)
MakeDENSO
Standard typeFXE22HR11
Gap (Nominal)1.1 (0.043)

SPARK PLUG SPECIFICATION

ALUMINUM WHEEL (CONVENTIONAL)

ItemLimit
Radial runoutLateral deflectionLess than 0.3 mm (0.012 in)
Vertical deflection
Allowable unbalanceDynamic (At flange)Less than 5 g (0.17 oz.) (one side)
Static (At flange)Less than 10 g (0.35 oz.)

ALUMINUM WHEEL (CONVENTIONAL) SPECIFICATION

ALUMINUM WHEEL (FOR TEMPORALLY USE)

ItemLimit
Radial runoutLateral deflectionLess than 1.5 mm (0.059 in)
Vertical deflection
Allowable unbalanceDynamic (At flange)Less than 5 g (0.17 oz.) (one side)
Static (At flange)Less than 10 g (0.35 oz.)

ALUMINUM WHEEL (FOR TEMPORALLY USE) SPECIFICATION
