ENGINE COMPARTMENT
Note. For circuit wiring diagram, see POWER SUPPLY ROUTING CIRCUIT in the POWER SUPPLY, GROUND & CIRCUIT ELEMENTS article in ELECTRICAL.
Scheme 1
| Fusible Link | Amps | Circuit |
|---|---|---|
| A | 140 A | Starting/Charging System & Fusible Links B, C, D, E |
| B | 100 A | In Fuse, Fusible Link and Relay Box: Fusible Links F, G, H, K, L, M, & Fuses 31-38, 61, 63 |
| C | 80 A | In IPDM E/R: Ignition Relay, CPU, & Fuses 48-51 |
| D | 60 A | In IPDM E/R: Tail Lamp Relay, Headlamp Relay, & Fuses 58-60 |
| E | 80 A | In Fuse Block (J/B): Acc.Relay, Blower Relay, Rear Window Defogger Relay, & Fuses 6-11 |
Fusible Link Holder Assignments
| Fusible Link/Fuse | Amps | Circuit |
|---|---|---|
| Fusible Link F | 50 A | Cooling Fans System |
| Fusible Link G | 30 A | Ignition Relay |
| Fusible Link H | 40 A | Fuses 61, 63 |
| Fusible Link I | Blank | |
| Fusible Link J | Blank | |
| Fusible Link K | 40 A | BCM, Seats, Memory Systems |
| Fusible Link L | 30 A | ABS System |
| Fusible Link M | 50 A | ABS System |
| Fuse 31 | 15 A | Horns, Starting/Charging |
| Fuse 32 | 30 A | Seats System |
| Fuse 33 | 10 A | Transmissions System |
| Fuse 34 | 15 A | Navigation, Sound Systems |
| Fuse 35 | 15 A | Seats System |
| Fuse 36 | 10 A | Transmissions System |
| Fuse 37 | Blank | |
| Fuse 38 | 10 A | Horns Systems |
| Fuse 61 | 10 A | Cruise Control System |
| Fuse 62 | Blank | |
| Fuse 63 | 10 A | Cruise Control System |
Fuse & Fusible Link Block Assignments
Scheme 2
| Fuse | Amps | Circuit |
|---|---|---|
| 41 | 15 A | Fuel Pump Relay |
| 42 | 10 A | Cooling Fans System |
| 43 | 10 A | Transmissions System |
| 44 | 10 A | BCM, Engine Controls System |
| 45 | 10 A | ABS, Electronic Power Steering, Engine Controls, Transmissions Systems |
| 46 | 15 A | Engine Controls System |
| 47 | 10 A | Instrument Cluster |
| 48 | 10 A | Steering Lock Relay |
| 49 | 10 A | A/C Relay |
| 50 | 15 A | ECM Relay, Engine Controls System |
| 51 | 15 A | CPU, Throttle Control Motor Relay |
| 52 | 10 A | Exterior Lights System |
| 53 | 10 A | Exterior Lights, Interior Lights Systems |
| 54 | 10 A | Headlights System |
| 55 | 10 A | Headlights System |
| 56 | 15 A | Headlights System |
| 57 | 15 A | Headlights System |
| 58 | 15 A | Front Fog Lamp Relay |
| 59 | Blank | |
| 60 | 30 A | Front Wiper Relay |
IPDM E/R Assignments
PASSENGER COMPARTMENT
Note. For circuit wiring diagram, see POWER SUPPLY ROUTING CIRCUIT in the POWER SUPPLY, GROUND & CIRCUIT ELEMENTS article in ELECTRICAL.
Scheme 3
| Fuse | Amps | Circuit |
|---|---|---|
| 1 | Blank | |
| 2 | 10 A | Supplemental Restraints System |
| 3 | 10 A | Headlights, Computer Data Lines, Navigation, Warning, Seats, A/C, Sound Systems |
| 4 | 10 A | Instrument Cluster, Exterior Lights Systems |
| 5 | Blank | |
| 6 | 10 A | Door Locks, Computer Data Lines, Instrument Cluster, Seats, Anti-Theft, Mirrors Systems |
| 7 | 10 A | BCM, Cruise Control System |
| 8 | 20 A | Sound System |
| 9 | 10 A | Push Button Ignition Switch, Anti-Theft, Door Locks System |
| 10 | 10 A | BCM, Seats, Mirrors, Memory Systems |
| 11 | 10 A | Instrument Cluster, A/C System |
| 12 | Blank | |
| 13 | 10 A | Defogger System |
| 14 | 20 A | Defogger System |
| 15 | 20 A | Defogger System |
| 16 | Blank | |
| 17 | Blank | |
| 18 | 15 A | Front Power Socket |
| 19 | 10 A | Navigation, Instrument Cluster, A/C, Sound Systems |
| 20 | 15 A | Console Power Socket |
| 21 | 15 A | A/C System |
| 22 | 15 A | A/C System |
Instrument Panel Fuse Block/Junction Box Assignments
