INSTALLATION

Installation is basically the reverse order of removal.

Replacement

Replace in-cabin microfilter.

Refer to " SCHEDULE 1 " and " SCHEDULE 2 ".

Affix a caution label inside the glove box when replacing filter.

Scheme 206

Scheme 207

Scheme 208

1. Remove ventilator ducts (left and right). Refer to " «EXPLODED VIEW»(ref-368799-S35971679862010081300000) ".
2. Remove mounting screws (A), and then remove center ventilator grilles (1) (left and right).

Installation is basically the reverse order of removal.

Scheme 209

1. Remove ventilator ducts (left and right). Refer to " «EXPLODED VIEW»(ref-368799-S35971679862010081300000) ".
2. Remove mounting screws (A), and then remove side ventilator grilles (1) (left and right).

Installation is basically the reverse order of removal.

REMOVAL

Remove front defroster grilles (1), using remover tools (A).

Scheme 210

Installation is basically the reverse order of removal.

Scheme 211

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Remove mounting screws (A), and then remove ventilator duct (left) (1) and ventilator duct (right) (2).

Installation is basically the reverse order of removal.

Scheme 212

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Remove mounting screw (A), and then adaptor duct (1).

Installation is basically the reverse order of removal.

Scheme 213

1. Remove side defroster nozzles. Refer to " «EXPLODED VIEW»(ref-368799-S35971679862010081300000) ".
2. Remove defroster nozzle (1).

Installation is basically the reverse order of removal.

Scheme 214

Scheme 215

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Remove clip (A), and then remove side defroster nozzle (left) (1).
3. Remove mounting clip (A).
4. Remove harness clip (B), and then remove side defroster nozzle (right) (1).

Installation is basically the reverse order of removal.

Remove front pillar garnishes Refer to " EXPLODED VIEW ".

Installation is basically the reverse order of removal.

Scheme 216

1. Remove console rear finisher. Refer to " «EXPLODED VIEW»(ref-368793-S41967435142010081300000) ".
2. Remove rear ventilator grille (1).

Installation is basically the reverse order of removal.

Scheme 217

1. Remove center console assembly. Refer to " «EXPLODED VIEW»(ref-368793-S41967435142010081300000) ".
2. Remove mounting screws (A), and then remove rear ventilator duct 1 (1).

Installation is basically the reverse order of removal.

Scheme 218

1. Remove console rear finisher. Refer to " «EXPLODED VIEW»(ref-368793-S41967435142010081300000) ".
2. Remove rear ventilator duct 2 (1).

Installation is basically the reverse order of removal.

Scheme 219

1. Remove foot grille (left) (1).
2. Remove foot grille (right) (1).

Scheme 220

Installation is basically the reverse order of removal.

Driver side

Scheme 221

1. Remove mounting screws (A), and then remove heater pipe cover (1).
2. Remove mounting screws (B), and then remove foot duct (left) (2).

Passenger side

Scheme 222

1. Set the temperature at 18°C (64°F). CAUTION: The angle may be out, when installing the air mix door motor to the air mix door, unless the above procedure is performed.
2. Disconnect the battery cable from the negative terminal.
3. Remove heater & cooling unit assembly. Refer to " «EXPLODED VIEW»(ref-368782-S19253574742010081300000) ".
4. Remove air mix door motor (passenger side). Refer to " «EXPLODED VIEW»(ref-368784-S02604192962010081300000) ".
5. Remove mode door motor and links. Refer to " «EXPLODED VIEW»(ref-368784-S02604192962010081300000) ".
6. Remove mounting screws (A), and then remove evaporator cover (1).
7. Remove mounting screws (B), and then remove foot duct (right) (2).

Installation is basically the reverse order of removal.

1. Remove instrument lower panel LH. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Remove mounting screw, and then remove heater duct.

Installation is basically the reverse order of removal.

Without Rear Ventilation

Scheme 223

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Remove mounting clips (A), and then remove rear floor duct 1 (1).

With Rear Ventilation

Scheme 224

1. Remove instrument panel assembly. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Remove mounting clips (A), and then remove rear floor duct 1 (1).

Installation is basically the reverse order of removal.

Scheme 225

Refer to " COMPONENTS " for symbols in the figure.

Scheme 226

Scheme 227

Scheme 228

1. Remove instrument lower panel RH. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Disconnect AWD control unit connector (AWD). Refer to " «EXPLODED VIEW»(ref-368804-S13942013792010081300000) ".
3. Disconnect ECM (1) connectors.
4. Remove mounting nuts (A), and then remove ECM with bracket attached.
5. Remove power steering control unit. Refer to " «EXPLODED VIEW»(ref-368836-S06415120762010081300000) ".
6. Disconnect intake door motor connector and blower motor connector.
7. Remove mounting bolt (A) and screw (B), from blower unit (1).
8. Remove blower unit. CAUTION: Move blower unit rightward, and remove locating pin (1 part) and joint. Then remove blower unit downward.

Installation is basically the reverse order of removal.

Scheme 229

Scheme 230

1. Remove instrument lower cover. Refer to " «EXPLODED VIEW»(ref-368793-S13132998042010081300000) ".
2. Disconnect blower motor connector.
3. Remove mounting screws (A), and then remove blower motor (1).

Installation is basically the reverse order of removal.
