Power Windows: Overview Hyundai Veloster I

Scheme 1

Operation Time Limiter

Maximal operation time of power window motor is limited to 15 sec (EEPROM programmable).

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. Remove the front door trim panel. (Refer to " «FRONT DOOR»(ref-609325-S13797109942014041600000) ")
2. Disconnect the connector from the motor. [Driver] [Assistant]
3. Connect the motor terminals No. 2 and No. 3 directly to battery voltage (12V) and connect the motor terminal No. 4 to ground (0V). Check that the motor operates smoothly. If the operation is abnormal, replace the motor. [Safety Power Window]
4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor. [General Window]

Scheme 7

Scheme 8

1. Remove the rear door trim panel. (Refer to " «REAR DOOR»(ref-609325-S35242427152014041600000) ")
2. Disconnect the 2P connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to " «FRONT DOOR»(ref-609325-S13797109942014041600000) ")
3. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch. [Auto Down] [Safety Up/Down]
4. Remove the grip holder cover after loosening 4 bolts.
5. Remove the grip holder bracket (A).
6. Remove the power window switch module (A) after loosening 4 screws.

Scheme 19

Scheme 20

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to " «FRONT DOOR»(ref-609325-S13797109942014041600000) ")
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.
5. Remove the power window switch after loosening 2 screws.

Scheme 21

Scheme 22

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim panel. (Refer to " «REAR DOOR»(ref-609325-S35242427152014041600000) ")
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.
5. Remove the power window switch after loosening 2 screws.
