Fuses & Relays: Overview Hyundai Veloster I

Fuses & Circuit Breakers 3 illustrations

Scheme 1

Scheme 1: Component Location

Scheme 2

Scheme 2

Scheme 3

Scheme 3: Components
Fuse Name(A)Circuit Protected
MULTI FUSEMDPS80AEPS Control Module
BLOWER40AE/R Fuse & Relay Box (Blower Relay)
DCT 140ATCM
RR HTD40AE/R Fuse & Relay Box (Rear Defogger Relay)
ALT125AE/R Fuse & Relay Box (Multi Fuse - DCT 1, MDPS, RR HTD, BLOWER), Alternator
ABS 230AMultipurpose Check Connector, ESC Module
B+ 250ASmart Junction Box (Power Window Relay, IPS Control Module (ARISU LT), Fuse - SAFETY POWER WINDOW, AMP)
B+ 150ALeak Current Autocut Device (Room Lamp Relay, Leak Current Autocut Switch, Fuse - INTERIOR LAMP, MULTIMEDIA, MEMORY). Fuse S/HEATER
FUSEC/FAN40AE/R Fuse & Relay Box (Cooling Fan (High) Relay, Cooling Fan (Low) Relay)
A/CON10AE/R Fuse & Relay Box (A/CON Relay)
FOG LP FRT10AE/R Fuse & Relay box (Fog Lamp Relay)
HORN15AE/R Fuse & Relay Box (Burglar Alarm Horn Relay, Horn Relay)
SUNROOF20APanorama Sunroof Motor
IG 240AIgnition Switch, PDM Relay Box (IG 2 Relay), E/R Fuse & Relay Box (Start Relay)
IG 140AIgnition Switch, PDM Relay Box (IG 1 Relay, ACC Relay)
SENSOR 120AECM
SENSOR 210AOil Control Valve #1 (Intake)/#2 (Exhaust), Purge Control Solenoid Valve, Variable Intake Solenoid Valve, Canister Close Valve, E/R Fuse & Relay Box (A/CON Relay), Cooling Fan (High) Relay, Cooling Fan (Low) Relay
SENSOR 315AECM, Oxygen Sensor (Up)/(Down), E/R Fuse & Relay Box (HAC Relay)
ECU 215AECM
DCT 315ATCM
F/PUMP15AE/R Fuse & Relay box (Fuel Pump Relay)
ABS 140AESC Module
ECU 130AE/R Fuse & Relay Box (Engine Control Relay, Fuse - ECU 2, ECU 3)
DCT 240ATCM
B+ 350ASmart Junction Box (Tail Lamp Relay, IPS Control Module (ARISU RT), Fuse - STOP LP, SMART KEY 1/2, INVERTER 2, DR LOCK)
ECU 310ASport Mode Switch

CIRCUIT SPECIFICATION (E/R FUSE & RELAY BOX)

* USE THE DESIGNATED FUSE AND RELAY ONLY
