Lighting System: Specifications Hyundai Veloster I

Exterior Lights 6 illustrations ~101 words

Specification

ItemBulb capacity (W)Lamp type
FrontHead lamp (High)55H7LL
Head lamp (low)55H7HPLL/H11B
Turn signal lamp28PY21W
Fog lamp27GE881
Position lampLEDLED
Turn signal lamp (Door mirror)LEDLED
RearStop lamp/tail lamp21/5LED
Turn signal lamp21PY21W
Backup lamp16W16W
License lamp5W5W
High mounted stop lampLEDLED
InteriorOverhead console lamp8FESTOON 8 W
Rear room lamp8FESTOON 8W
Luggage lamp5FESTOON 5W

Scheme 1

Scheme 1: Component Location
Scheme 1: Component Location

Scheme 2

Scheme 2: Component
Scheme 2: Component

Scheme 3

Scheme 3: Removal
Scheme 3: Removal

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front bumper. (Refer to " «FRONT BUMPER»(ref-609306-S41736271712014041600000) ".
  3. Loosening the head lamp mounting bolts (3EA) and disconnect the head lamp connector (B). Then, remove the head lamp assembly (A). NOTE: Take care not to scratch the head lamp lens or fender. NOTE: Take care that holding clip (A) is not to be damaged.
  4. Remove the dust caps from the head lamp assembly after turning in the counter clock-wise direction.
