Airbag Modules & Clock Spring: Overview Hyundai Veloster I

Airbag 13 illustrations ~555 words

Description

Driver Airbag (DAB) is installed in the steering wheel and electrically connected to SRSCM via the clock spring. It protects the driver by deploying the airbag when frontal crash occurs. The SRSCM determines deployment of the Driver Airbag (DAB).

CAUTIONNever attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 1

Scheme 1: Components

Scheme 2

Scheme 2: Removal

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5
  1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
  2. Turn the steering wheel so that the front wheels can face straight ahead.
  3. Remove the driver airbag module mounting bolts (2EA).
  4. Remove the wiring fixing clip (C), and then release the connector locking pin to disconnect the driver airbag module connector (B). CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover facing up.
  5. Remove the steering wheel and steering wheel column shroud. (Refer to " «STEERING COLUMN AND SHAFT»(ref-609297-S07257609932014041600000) ")
  6. Disconnect the clock spring connector, then remove the clock spring.

The passenger airbag (PAB) is installed inside the crash pad and protects the front passenger in the event of a frontal crash. The SRSCM determines if and when to deploy the PAB.

CAUTIONNever attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 6

Scheme 6: Components

Scheme 7

Scheme 7: Removal

Scheme 8

Scheme 8
  1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
  2. Remove the glove box housing. (Refer to " «CRASH PAD»(ref-609328-S38971345422014041600000) ")
  3. Disconnect the passenger airbag connector (A) and remove the PAB mounting bolt (B).
  4. Remove the crash pad. (Refer to " «CRASH PAD»(ref-609328-S38971345422014041600000) ") NOTE: Replace the crash pad which is damaged while PAB is deployed.
  5. Remove the mounting bolts from the crash pad. Then remove the passenger airbag. CAUTION: The removed airbag module should be stored in a clean, dry place with the airbag cushion up.

Scheme 9

Scheme 9: Installation
  1. Remove the ignition key from the vehicle.
  2. Disconnect the battery negative cable from battery and wait for at least three minutes before beginning work.
  3. Place a passenger airbag on the crash pad and tighten the passenger airbag mounting bolts. Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  4. Install the crash pad. (Refer to " «CRASH PAD»(ref-609328-S38971345422014041600000) ")
  5. Tighten the passenger airbag mounting bolts. Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  6. Connect the passenger airbag harness connector to the SRS main harness connector.
  7. Reinstall the glove box housing. (Refer to " «CRASH PAD»(ref-609328-S38971345422014041600000) ")
  8. Reconnect the battery negative cable.
  9. After installing the passenger airbag (PAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

The Side Airbags (SAB) are installed inside the front seat and protects the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of side airbag by using Side Impact Sensor (SIS) signal.

CAUTIONNever attempt to measure the circuit resistance of the airbag module (squib) even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 10

Scheme 10: Components

Curtain airbags are installed inside the headliner (LH and RH) and protect the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of curtain airbag by using side impact sensor (SIS) signal.

CAUTIONNever attempt to measure the circuit resistance of the airbag module even if you are using the specified tester. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 11

Scheme 11: Components

Scheme 12

Scheme 12: Removal

Scheme 13

Scheme 13
  1. Disconnect the battery negative cable and wait for at least 3 minutes before beginning work.
  2. Remove the roof trim. (Refer to " «ROOF TRIM REPLACEMENT»(ref-609328-S30504551502014041600000) ").
  3. Disconnect the curtain airbag harness connector (A).
  4. After loosening the mounting bolts remove the curtain airbag.
