Wiring diagram: Body control modules — Ips control module circuit Hyundai Tucson II

Components on these wiring diagrams 49

Click a component to highlight it on every diagram it appears on.

• B-Can
• Backup Lamp Relay
• Backup Lamp Relay Ctrl Rear Defogger Relay Dri Pass Ctrl
• Burglar Alarm Relay
• Burglar Alarm Relay Ctrl
• Deicer Relay Ctrl
• Door Door B/Alarm Lock Un Lock Horn
• Door Locks, Anti-Theft Systems
• Door Unlock Relay
• E/R Fuse, Relay Box
• Ground
• Headlamp Low Signal
• I/P Junction Box
• I/P-A
• I/P-B
• I/P-C
• I/P-D
• I/P-E
• I/P-F
• I/P-H
• I/P-J
• Ips 0
• Ips 1
• Ips 2
• Ips 3
• Ips 4
• Ips 5 Ips 6 Ips 7
• Ips Control
• Ips Control Mcu B+ Module
• Ips Control Module
• Module 1 Fuse
• Module 2 Fuse
• Multi B+1 B+2 Fuse Fuse Fuse
• On Input
• P-Gnd
• Pass Door Key Switch
• Power Connector
• Power Window Relay
• Power Window Relay Control
• Rear Door Switch
• Rear Lh Rear Rh
• Relay Control
• Room Lp Fuse
• S Gnd
• Seat Tail Gate Belt Handle Buckle Hi Lo Switch Switch
• Switch Lever "R" Input
• Tail Gate Relay Open Ctrl Switch
• Two Turn Unlock Relay Hood Ctrl Switch
• Warning Systems
