Installation
- Install the start/stop button.
- Install the left air vent.
Scheme 36
Scheme 37
Scheme 38
- Disconnect the negative (-) battery terminal.
- Remove the floor console. (Refer to the «CONSOLE»(ref-583674-S06879868982013102900000) .)
- Disconnect the connector (B), then remove the fob holder assembly (A) after releasing the hook (C).
- Install the fob holder assembly.
- Install the floor console.
- Install the negative (-) battery terminal.
Scheme 39
Scheme 40
Scheme 41
Scheme 42
- Disconnect the negative (-) battery terminal.
- Remove the main crash pad. (Refer to the «CRASH PAD»(ref-583674-S03536476502013102900000) .)
- Remove the power distribution module (A) after loosening bolts (2EA).
Scheme 43
- Remove the negative (-) battery terminal.
- Remove the front seat heater switch module. (Refer to «FRONT SEAT»(ref-583701-S27577980502013102900000) .)
- After removing the bolts (2EA) and connector, remove PDM relay box (A).
Scheme 44
Scheme 45
Scheme 46
Scheme 47
- It will be able to diagnose defects of Smart key with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
- Select model and "Smart key system (Button start)" menu if you want to check PDM.
- Select "PDM" in the menu.
- Select "Current Data", if you want to check current data of PDM. It provides the input/output status of each module.
- If you want to check PDM data operation forcefully, select "Actuation test".
