Back View Camera System: Overview Hyundai Tucson II

Collision/avoidance 5 illustrations ~121 words

Scheme 1

Scheme 1: Component Location
Scheme 1: Component Location

Scheme 2

Scheme 2: Circuit Diagram
Scheme 2: Circuit Diagram

Description

Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the R position. This system is a supplemental system that shows behind the vehicle through the ECM (Reverse Display Room Mirror) mirror or AVN head unit while backing-up.

WARNINGThis system is a supplementary function only. It is the responsibility of the driver or always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there is a dead zone that can't see through the camera.

Scheme 3

Scheme 3: Removal
Scheme 3: Removal

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Remove the tailgate trim in the trunk after removing the screws and clips. (Refer to the " «TAILGATE»(ref-583703-S11397519982013102900000) ")
  2. Remove the tailgate garnish (A) after disconnecting the connector and removing the nuts.
  3. Remove the back view camera (A) after loosening the screws (2EA).
  4. Disconnect the connector (A), and then remove the back view camera module (B).
