Wiring diagram: Computer data lines 2.7l — 2.7l, computer data lines circuit Hyundai Tucson I

Components on these wiring diagrams 22

Click a component to highlight it on every diagram it appears on.

• 5 8 Automatic A/C Manual A/C
• A/C Control Module
• ABS Control Module
• ABS Fusible Link 1
• ABS Fusible Link 2
• Data Link Connector
• E/R Fuse, Relay Box
• Esc Control Module
• Fuse 22
• Fuse 38 Junction Box
• I/P
• I/P-A
• I/P-B
• I/P-C
• Immobilizer Control Module
• Module
• Multipurpose Check Connector
• SRS Control Module
• Tire Pressure Monitoring
• Vehicle Speed Sensor
• W/O Esc
• W/O Immobilizer
