Blower Controls: Overview Hyundai Tucson I

Manual HVAC System 15 illustrations ~285 words

Scheme 1

Scheme 1: COMPONENT LOCATION

Scheme 2

Scheme 2: COMPONENTS

Scheme 3

Scheme 3: REPLACEMENT
  1. Disconnect the negative cable from the battery.
  2. Remove the crash pad (see «CRASH PAD»(ref-276690-S28828737492008011000000) ).
  3. Disconnect the connectors from the blower relay the blower motor, the blower resistor (or power transistor) and the fresh and recirculation actuator. Remove the self-tapping screws (A), the mounting nut (B), the mounting bolt (C) and the blower unit (D). NOTE: Make sure that there is no air leaking out of the blower and duct joints.
  4. Install in the reverse order of removal.

Scheme 4

Scheme 4: COMPONENT LOCATION

DESCRIPTION

Motor: Magnet diameter 68.2

ItemSpecifications
Time ratingContinuous
Rated voltageDC 12V
Speed in rated load3,000 +/- 10% RPM
Power in rated250W grade
Rotation directionCCW

ITEM SPECIFICATION

Scheme 5

Scheme 5: CONNECTOR

There should be continuity between No.3 and No.4 terminals when power and ground are connected to the No.1 and No.2 terminals, and there should be no continuity when power is disconnected.

  1. Rated voltage: DC 12V
  2. Rated load current: DC 12V, 25A (Motor load)

Scheme 6

Scheme 6: CONNECTOR

Scheme 7

Scheme 7: CIRCUIT DIAGRAM

Scheme 8

Scheme 8: COMPONENT LOCATION
  1. Rated voltage: DC 12V
  2. Working voltage range: DC 9 - 16V
  3. Working temp, range: -30 ~ 60°C
  4. Resistance temp, range: -40 - 85°C

Scheme 9

Scheme 9: CONNECTOR

Scheme 10

Scheme 10: COMPONENT LOCATION
  1. Rated voltage: DC 12V
  2. Rated load: Blower motor
  3. Standard test Temp.: 20°C
  4. Operation Temp.: -30 - +70°C

Scheme 11

Scheme 11: CONNECTOR

Scheme 12

Scheme 12: CIRCUIT DIAGRAM

General performance

  1. Rate voltage: DC 12V
  2. Rate load: 1.5kgf.cm
  3. Operating time: 3.5 + 1.0 sec.
  4. Rate current: Max. 0.1 A
  5. Lock current: Max. 0.55A
  6. Locked torque: Max. 6kgf.cm
  7. Noise: Max. 43dB
  8. Use voltage: DC 10 ~ 15V
  9. Use temp.: -40 - 80°C

Scheme 13

Scheme 13: CONNECTOR

Scheme 14

Scheme 14: CIRCUIT DIAGRAM

Scheme 15

Scheme 15: REPLACEMENT
  1. Disconnect the 7P connector (A) from the inlet actuator (C). Remove the self-tapping screws (B) and the inlet actuator (C) from the blower unit (D).
  2. Install in the reverse order of removal. After installation, make sure the inlet actuator (C) runs smoothly.
