SPECIFICATIONS
| Items | Specifications |
|---|---|
| Rated voltage | 12V |
| Load | Max. 200mA (Relay load) |
| Detection illuminations Tail lamp/Head lamp | ON: 24 +/- 5.2 (Lux), 0.81 +/- 0.05V OFF: 48 +/- 10.5 (Lux), 1.41 +/- 0.05V |
SPECIFICATIONS
Scheme 1
Scheme 2
Also refer to EXTERIOR LIGHTS & INTERIOR LIGHTS .
Scheme 3
- Remove the photo and auto light sensor (A) from the center crash pad upper.
- Disconnect the 8P connector (B) from the auto light unit then inspect the connector on the wire harness side, as shown in the chart. TESTING AUTO LIGHT UNIT CIRCUITS Tester connection Condition Specified condition 2-Ground Constant 5V Tail lamp switch ON 0V 3-Ground Ignition switch ON 12V 5-Ground Auto light switch ON Continuity 6-Ground Ignition switch ON 12V 1-Ground Constant Continuity
- If the circuit is not as specified, inspect the circuits connected to other parts.
