FUSIBLE LINKS & FUSES INFORMATION
Note. * Use designated fuses only.
| DESCRIPTION | AMPERAGE | CIRCUIT PROTECTED | |
|---|---|---|---|
| Fusible Links | BATT #2 | 30A | Ignition Switch (IG2, Start) Fuse (4, 21, 23, 29-31, 35-37) Power Connector |
| BLOWER | 30A | Blower Relay | |
| ABS #2 | 40A | ABS Control Module ESC Control Module Multipurpose Check Connector | |
| ABS #1 | 40A | ABS Control Module ESC Control Module Multipurpose Check Connector | |
| C/FAN | 50A | Cooling fan Relay #1/ #2 (2.7L Gas, 2.0L Gas) | |
| BATT #1 | 50A | Ignition Switch (IG2, Start) Fuse (4, 21, 23, 29-31, 35-37) Power Connector | |
| ECU | 30A | A/C Relay ATM Control Relay Engine Control Relay Fuel Pump Relay Generator | |
| IGN | 30A | Ignition Switch (IG1, ACC) Start Relay | |
| H/LP (LOW) | 15A | Head Lamp Relay (LOW) | |
| Fuses | H/LP (HI) | 15A | Head Lamp Relay (HIGH) |
| A/CON | 15A | A/C Relay | |
| HORN | 15A | Horn Siren Relay | |
| FRT/FOG | 15A | Front Fog Lamp Relay Multipurpose Check Connector | |
| DRL | 15A | DRL Control Module | |
| INJ | 15A | Injector (GAS) | |
| SNSR | 10A | Cooling Fan Relay #1, #2 CPS (GAS) ECM/PCM ISA (GAS) MAF Sensor Oxygen Sensor (GAS) SMATRA (2.0L GAS) Stop Lamp Switch (DSL) | |
IDENTIFYING FUSIBLE LINKS & FUSES (ENGINE COMPARTMENT)
FUSE INFORMATION
CIRCUIT
Note. *Use designated fuses only.
| FUSE | AMPERAGES | CIRCUIT PROTECTED |
|---|---|---|
| 1 | 30A | Left Power Window Switch |
| 2 | 30A | Right Power Window Switch |
| 3 | 10A | Glove Box Lamp Illuminations Right Rear Combination Lamp |
| 4 | 30A | Rear Defogger Relay |
| 5 | 15A | SRS Control Module |
| 6 | 10A | Instrument Cluster ETACM/TACM |
| 7 | 10A | Head Lamp (LH) License Lamp (LH) Rear Combination Lamp (LH) |
| 8 | 10A | Audio Digital Clock Power Outside Mirror Folding Module Power Outside Mirror & Mirror Folding Switch |
| 9 | 20A | Cigarette Lighter |
| 10 | 15A | (SPARE) |
| 11 | 10A | Rear Fog Lamp Relay |
| 12 | 10A | Left Power Outside Mirror & Mirror Folding Module Right Power Outside Mirror & Mirror Folding Module Rear Defogger Switch |
| 13 | 10A | Audio |
| 14 | 20A | Ignition Coil (2.7L GAS) |
| 15 | 10 | Immobilizer Control Module (2.7L GAS) |
| 16 | 15A | Rear Power Outlet #1/ #2 |
| 17 | 10A | (Not Used) |
| 18 | 20A | Left Front Seat Warmer Switch Right Front Seat Warmer Switch |
| 19 | 10A | Burglar Alarm Relay Transaxle Range Switch Ignition Lock Switch |
| 20 | 10A | Burglar Alarm Relay Transaxle Range Switch Ignition Lock Switch |
| 21 | 30A | Ignition Switch (IG2, START) |
| 22 | 10A | A/C Control Module Courtesy Lamps (Room) Digital Clock ETACM/TACM Key Reminder Switch |
| 23 | 20A | Audio Amp. # 2, Sub Woofer |
| 24 | 10A | Auto Light & Photo Sensor Hazard Switch Transaxle Range Sensor |
| 25 | 10A | Instrument Cluster Pre-Excitation Resistor |
| 26 | 10A | Safety Relay |
| 27 | 10A | A/C Control Relay Blower Relay ETACM/TACM Sunroof Controller |
| 28 | 10A | DRL Control Module Fuel Filter Heater Relay Head Lamp Relay |
| 29 | 15A | Hazard Relay Hazard Switch Immobilizer Control Module (2.7L GAS) |
| 30 | 20A | Door Lock/Unlock Relay Sunroof Controller |
| 31 | 15A | Power Outside Mirror Folding Module Stop Lamp Switch |
| 32 | 10A | (Not Used) |
| 33 | 10A | Cruise ControlModule ECM ESP Switch PCM Pulse Generator 'A'/'B' Stop Lamp Switch TCM TCS Switch Vehicle Speed Sensor 4WD ECM |
| 34 | 30A | Front Wiper Motor Front Wiper Relay Multifunction Switch |
| 35 | 20A | 4WD/ECM |
| 36 | 10A | Windshield Defogger Relay |
| 37 | 10A | TCM (2.7L GAS) |
| 38 | 10A | ABS Control Module ESP Control Module G-Sensor Multipurpose Check Connector |
IDENTIFYING FUSES (PASSENGER COMPARTMENT)
