Engine Electrical System - General Information: Other Hyundai Tucson I

Charging System 7 illustrations ~332 words

IGNITION SYSTEM

ItemSpecifications
2.72.0
Ignition coilTypeMold coil typeMold coil type
Primary resistance0.96 +/- 10%(ohms)0.58 +/- 10%(ohms)
Secondary resistance12.5 +/- 15%8.8 +/- 15%(ohms)
Spark plugsUnleadedNGKIFR5G-11PFR5N-11
CHAMPIONRC10PYPB4
Gap1.0 mm ~ 1.1 mm

IGNITION SYSTEM SPECIFICATIONS

STARTING SYSTEM

ItemSpecifications
2.72.0
StarterTypeReduction drive (with planetary gear)
Rated voltage12V, 1.2KW12V, 1.2KW
No. of pinion teeth88
No-load characteristicsVoltage11V11V
Amperage90A, MAX90A, MAX
Speed2,800rpm, MIN3,000rpm, MIN
Commutator diameterStandard29.4 mm (1.157 in.)
Limit28.4 mm (1.118 in.)
Undercut depthStandard0.5 mm (0.02 in.)
Limit0.2 mm (0.008 in.)

STARTING SYSTEM SPECIFICATIONS

CHARGING SYSTEM

ItemSpecifications
2.72.0
AlternatorTypeInternal sensing
Rated voltage13.5V, 120A13.5V, 90A
Speed1,000 ~ 18,000 rpm
Voltage regulatorElectronic built-in type
Regulator setting voltage14.55 +/- 0.2V14.55 +/- 0.2V
Temperature compensation3.5 +/- 1mV/°C7 +/- 3mV/°C
BatteryTypeMF 70 AHMF 60 AH
Cold cranking amperage at-18°C (0°F)600A550A
Reserve capacity113min92min
Specific gravity at 20°C (77°F)1.280 +/- 0.011.280 +/- 0.01

CHARGING SYSTEM SPECIFICATIONS

Note. COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature. RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7° C (80° F)

SymptomSuspect areaRemedy
Engine will not start or is hard to start (Cranks OK)Ignition lock switchInspect ignition lock switch, or replace as required
Ignition coilInspect ignition coil, or replace as required
Spark plugsInspect spark plugs, or replace as required
Ignition wiring disconnected or brokenRepair wiring, or replace as required
Rough idle or stallsIgnition wiringRepair wiring, or replace as required
Ignition coilInspect ignition coil, or replace as required
Engine hesitates / poor accelerationSpark plugs Ignition wiringInspect spark plugs or replace as required Repair wiring, or replace as required
Poor mileageSpark plugsInspect spark plugs or replace as required

IGNITION SYSTEM CHART

SymptomSuspect areaRemedy
Charging warning indicator does not light with ignition switch "ON" and engine off.Fuse blownCheck fuses
Light burned outReplace light
Wiring connection looseTighten loose connection
Electronic voltage regulatorReplace voltage regulator
Charging warning indicator does not go out with engine running. (Battery requires frequent recharging)Drive belt loose or wornAdjust belt tension or replace belt
Battery cable loose, corroded or wornInspect cable connection, repair or replace cable
Electronic voltage regulator or generatorReplace voltage regulator or generator
WiringRepair or replace wiring
OverchargeElectronic voltage regulatorReplace voltage regulator
Voltage sensing wireRepair or replace wiring
DischargeDrive belt loose or wornAdjust belt tension or replace belt
Wiring connection loose or short circuitInspect wiring connection, repair or replace wiring
Electronic voltage regulator or generatorReplace voltage regulator or generator
Poor groundingInspect ground or repair
Worn batteryReplace battery

CHARGING SYSTEM CHART

SymptomSuspect areaRemedy
Engine will not crankBattery charge lowCharge or replace battery
Battery cables loose, corroded or worn outRepair or replace cables
Transaxle range switch (Vehicle with automatic transaxle only)Refer to appropriate AUTOMATIC TRANSAXLE article
Fuse blownReplace fuse
Starter motor faultyReplace
Ignition switch faultyReplace
Engine cranks slowlyBattery charge lowCharge or replace battery
Battery cables loose, corroded or worn outRepair or replace cables
Starter motor faultyReplace
Starter keeps runningStarter motorReplace
Ignition switchReplace
Starter spins but engine will not crankShort in wiringRepair wiring
Pinion gear teeth broken or starter motorReplace
Ring gear teeth brokenReplace fly wheel or torque converter

STARTING SYSTEM CHART

THE MICRO 570 ANALYZER

The MICRO 570 Analyzer provides the ability to test the charging and starting systems, including the battery, starter and alternator.

CAUTIONBecause of the possibility of personal injury, always use extreme caution and appropriate eye protection when working with batteries.

Scheme 44

Scheme 44
Scheme 44

KEYPAD

The MICRO570 buttons on the key pad provide the following functions

Scheme 45

Scheme 45: KEYPAD
Scheme 45: KEYPAD

Scheme 46

Scheme 46: BATTERY TEST PROCEDURE
Scheme 46: BATTERY TEST PROCEDURE

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
  1. Connect the tester to the battery. Red clamp to battery positive (+) terminal. Black clamp to battery negative (-) terminal. CAUTION: Connect clamps securely. If "CHECK CONNECTION" message is displayed on the screen, reconnect clamps securely.
  2. The tester will ask if the battery is connected "IN A VEHICLE" or "OUT OF A VEHICLE". Make your selection by pressing the arrow buttons; then press ENTER.
  3. Choose either CCA or CCP and press the ENTER button. NOTE: CCA: Cold cranking amps, is an SAE specification for cranking batteries at 0° F (-18° C). CCP: Cold cranking amps, is an SAE specification for Korean manufacturer's for cranking batteries at 0° F (-18° C).
  4. Set the CCA value displayed on the screen to the CCA value marked on the battery label by pressing up and down buttons and press ENTER. NOTE: The battery ratings (CCA) displayed on the tester must be identical to the ratings marked on battery label.
  5. The tester (Micro 570) displays battery test results including voltage and battery ratings. A relevant action must be given according to the test results by referring to the battery test results as shown in the table below.
  6. To conduct starter test, continuously, press ENTER.

More articles — Engine Electrical System - General Information
