Emission Control System: Specifications Hyundai Tiburon II

Emission Applications 12 illustrations

SPECIFICATIONS

ComponentsFunctionRemarks
Crankcase Emission System Positive Crankcase Ventilation (PCV) valveHC reductionVariable flow rate type
Evaporative Emission System EVAP Canister EVAP Canister Purge Solenoid ValveHC reductionDuty control solenoid valve
Exhaust Emission System MFI system (air-fuel mixtrue control device) Three-way catalytic converterCO, HC, NOx reduction CO, HC, NOx reductionHeated oxygen sensor feedback type Monolithic type
MFI : Multiport Fuel Injection EVAP : Evaporative Emission

General Specifications

Scheme 3

Scheme 3: SERVICE STANDARD
Scheme 3: SERVICE STANDARD

TIGHTENING TORQUE

ItemNmKg.cm
Positive Crankcase Ventilation Valve8 ~ 1280 ~ 120

Torque Specifications

Scheme 4

Scheme 4: TROUBLESHOOTING
Scheme 4: TROUBLESHOOTING

Scheme 5

Scheme 5: COMPONENTS
Scheme 5: COMPONENTS

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: SCHEMATIC DRAWING [2.0 I4]
Scheme 9: SCHEMATIC DRAWING [2.0 I4]

Scheme 10

Scheme 10: SCHEMATIC DRAWING [2.7 V6]
Scheme 10: SCHEMATIC DRAWING [2.7 V6]

Scheme 11

Scheme 11: VACUUM HOSES LAYOUT
Scheme 11: VACUUM HOSES LAYOUT

Scheme 12

Scheme 12: COMPONENTS
Scheme 12: COMPONENTS

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14: OPERATION
Scheme 14: OPERATION
