Blower Controls: Overview Hyundai Tiburon II

Automatic HVAC System 13 illustrations ~176 words

Scheme 55

Scheme 55: COMPONENT LOCATION

Scheme 56

Scheme 56: COMPONENTS

DESCRIPTION

There should be continuity between No. 3 and No. 4 terminals when power and ground are connected to the No. 1 and No. 2 terminals, and there should be no continuity when power is disconnected.

  1. Rated voltage : DC 12V
  2. Operation voltage range : DC 10V ~ DC 15V
  3. Rated load current : DC 12V, 25A (Motor lord)

Scheme 57

Scheme 57: CONNECTOR

Scheme 58

Scheme 58: CIRCUIT DIAGRAM

Scheme 59

Scheme 59: COMPONENT LOCATION

Motor : Magnet i 70

Scheme 60

Scheme 60: DESCRIPTION

Scheme 61

Scheme 61: CONNECTOR
  1. Rated voltage : DC 12V
  2. Rated load : Blower motor
  3. Standard test Temp. : 20DEG
  4. Operation Temp. : -30DEG ~ +70DEG
  5. Resistor off - Time requirement for blower motor locking

Scheme 62

Scheme 62

Scheme 63

Scheme 63: CHARACTERISTICS

Scheme 64

Scheme 64: CONNECTOR

Scheme 65

Scheme 65: CIRCUIT DIAGRAM
  1. Rated voltage : DC 12V
  2. Power consumption : Max. 240W
  3. Operating assurance range : -30°C ~ +70°C, 10 ~ 15V
  4. Performance assurance range : -30°C ~ +60°C, 10 ~ 15V

Scheme 66

Scheme 66: CONNECTOR

Scheme 67

Scheme 67: CIRCUIT DIAGRAM AND IMPORTANT PERFORMANCE OF PARTS COMPOSED CIRCUIT
  1. A. Power transistor : Equivalent to MOTOROLA MJ11032 (Pc = 300W, lc = 50A)
  2. B. Fuse : 250V, 15A, 128°C

Condenser : 50V
