SUB-SWITCH

When ignition switch is in ON position, battery voltage is applied to the power window relay through 10-amp fuse No. 10 (Accent) or fuse No. 16 (Elantra and Tiburon), located in passenger compartment fuse panel. When relay is energized, battery voltage is supplied to the master switch assembly through closed relay contacts. When a sub-switch is operated, battery voltage is applied to the power window motor. The motor is then grounded through the opposite contact in the respective sub-switch and master switch assembly.

FRONT DOOR GLASS

Note. Check and adjust clearances as specified. (Scheme 5)and (Scheme 6). Information on other models is not available from manufacturer.

Delta Sash (Tiburon)

Using bolt at bottom of delta sash, adjust distance between delta sash and door inner panel to.669" (17 mm). (Scheme 7) Tighten delta sash bolt and adjust bolt to 84-120 INCH lbs. (9-14 N.m).

Channel (Tiburon)

Using bolt at bottom of channel, adjust distance between channel and door inner panel to.728" (18.5 mm). (Scheme 8) Tighten channel mounting and adjustment bolt to 84-120 INCH lbs. (9-14 N.m).

Regulator (Tiburon)

Using regulator adjusting bolt, adjust distance between channel and door inner panel to.571" (14.5 mm). (Scheme 9) Tighten regulator mounting and adjusting bolt to 85-120 INCH lbs. (9-14 N.m).

Stabilizers (Tiburon)

Loosen stabilizer nuts. Adjust and set front and rear stabilizers to specified clearance. (Scheme 10) Tighten stabilizer nuts to 85-120 INCH lbs. (9-14 N.m).

Stopper (Tiburon)

1. With glass fully closed, glass edge must be parallel to weatherstrip at roof section and 2 stoppers must simultaneously come into contact. Loosen 2 stopper mounting bolts. Adjust as necessary. (Scheme 11) Tighten stopper catch to 85-120 INCH lbs. (9-14 N.m). Tighten glass stopper to 36-48 INCH lbs. (4-6 N.m).
2. Close door and glass fully. Check for water leaks. Adjust as necessary. Install door trim seal and trim panel.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

ALL WINDOWS INOPERATIVE

If all power windows are inoperative, check the following and repair as necessary

1. Blown fusible link. Check for short to ground and repair as necessary.
2. Blown power window fuse. Check for short to ground. See «WIRING DIAGRAMS»(ref-4185-S17444195412000061500000) .
3. Defective sub-switch. See «POWER WINDOW SUB-SWITCH»(ref-4185-S32998186202000061500000) under COMPONENT TESTS.
4. Defective power window main switch. See «POWER WINDOW MAIN SWITCH»(ref-4185-S03238615402000061500000) under COMPONENT TESTS.
5. Defective power window relay. See «POWER WINDOW RELAY»(ref-4185-S15007230552000061500000) under COMPONENT TESTS.
6. Defective wiring harness. See «WIRING DIAGRAMS»(ref-4185-S17444195412000061500000) .

DRIVER'S WINDOW INOPERATIVE

If only driver's side window is inoperative, check the following and repair as necessary

1. Defective power window main switch. See «POWER WINDOW MAIN SWITCH»(ref-4185-S03238615402000061500000) under COMPONENT TESTS.
2. Defective motor. See «POWER WINDOW MOTORS»(ref-4185-S07680290862000061500000) under COMPONENT TESTS.
3. Defective wiring harness. See «WIRING DIAGRAMS»(ref-4185-S17444195412000061500000) .

PASSENGER'S WINDOW INOPERATIVE

If only passenger's window is inoperative, check the following and repair as necessary

1. Defective passenger power window switch. See «POWER WINDOW MAIN SWITCH»(ref-4185-S03238615402000061500000) under COMPONENT TESTS.
2. Defective motor. See «POWER WINDOW MOTORS»(ref-4185-S07680290862000061500000) under COMPONENT TESTS.
3. Defective wiring harness. See «WIRING DIAGRAMS»(ref-4185-S17444195412000061500000) .

POWER WINDOW MOTORS

Remove motor to be tested. Apply battery voltage across motor terminals. Motor should operate smoothly. Reverse polarity and ensure motor operates smoothly in opposite direction. If motor does not test as specified, replace power window motor.

Sonata

1. Remove power window relay from power distribution box. Check continuity between power window relay terminals No. 85 and 86, and between terminals No. 30 and 87. Continuity should exist between terminals No. 85 and 86. Continuity should not exist between terminals No. 30 and 87. If continuity is as specified, go to next step. If continuity is not as specified, replace power window relay.
2. Apply battery voltage between terminals No. 85 and 86. Check continuity between terminals No. 30 and 87. If continuity exists, power window relay is okay. If continuity does not exist, replace power window relay.

Accent, Elantra & Tiburon

1. Remove power window relay from power distribution box. Check continuity between power window relay terminals No. 3 and 5, and between terminals No. 1 and 2. (Scheme 12) Continuity should exist between terminals No. 3 and 5. Continuity should not exist between terminals No. 1 and 2. If continuity is as specified, go to next step. If continuity is not as specified, replace power window relay.
2. Apply battery voltage and ground to terminals No. 3 and 5. Check continuity between terminals No. 1 and 2. If continuity exists, power window relay is okay. If continuity does not exist, replace power window relay.

Scheme 12

Accent

Remove power window main switch. Check continuity between specified terminals with switch in specified position. See MAIN SWITCH CONTINUITY (ACCENT) table. (Scheme 13) If continuity is not as specified, replace main switch.

MAIN SWITCH CONTINUITY (ACCENT)

Scheme 13

Elantra

Remove main switch. Check continuity between specified terminals with switch in specified position. See MAIN SWITCH CONTINUITY (ELANTRA) table. (Scheme 14) If continuity is not as specified, replace main switch.

MAIN SWITCH CONTINUITY (ELANTRA)

Scheme 14

Scheme 15

Remove main switch. Check continuity between specified terminals with switch in specified position. See MAIN SWITCH CONTINUITY (SONATA) table. (Scheme 13) If continuity is not as specified, replace main switch.

MAIN SWITCH CONTINUITY (SONATA)

Tiburon

Remove main switch. Check continuity between specified terminals with switch in specified position. See MAIN SWITCH CONTINUITY (TIBURON) table. (Scheme 15) If continuity is not as specified, replace main switch.

MAIN SWITCH CONTINUITY (TIBURON)

POWER WINDOW SUB-SWITCH

Remove sub-switch to be tested. Check continuity between specified terminals with switch in specified position. See SUB-SWITCH CONTINUITY table. (Scheme 16) If continuity is not as specified, replace sub-switch.

SUB-SWITCH CONTINUITY

Scheme 16

WINDOW MOTOR
